Buildings.Templates.Components.Validation
Package with validation models
Information
This package contains validation models for the classes within Buildings.Templates.Components.
Extends from Modelica.Icons.ExamplesPackage (Icon for packages containing runnable examples).
Package Content
| Name | Description |
|---|---|
 Coils
|
Validation model for coil components |
| Dampers
|
Validation model for damper components |
| Fans
|
Validation model for fans components |
| PumpMultipleRecord
|
Validation model for parameter propagation with the multiple-pump record |
| Pumps
|
Validation model for pump components |
| Routing
|
Validation model for routing components |
| Sensors
|
Validation model for sensor components |
| Valves
|
Validation model for valve components |
Buildings.Templates.Components.Validation.Coils
Validation model for coil components
Information
This model validates the models within Buildings.Templates.Components.Coils by exposing them to a fixed pressure difference on the air side. Models representing a water-based coil with valve are also exposed to a fixed pressure difference on the water side, and a varying valve opening from fully closed to fully open position. Other coil models are controlled with a signal varying from 0 to 1.
Extends from Modelica.Icons.Example (Icon for runnable examples).
Parameters
| Type | Name | Default | Description |
|---|---|---|---|
| replaceable package MediumAir | Buildings.Media.Air | Air medium | |
| replaceable package MediumLiq | Buildings.Media.Water | HW or CHW medium | |
| Dynamics | |||
| Conservation equations | |||
| Dynamics | energyDynamics | Modelica.Fluid.Types.Dynamic... | Type of energy balance: dynamic (3 initialization options) or steady state |
Connectors
| Type | Name | Description |
|---|---|---|
| replaceable package MediumAir | Air medium | |
| replaceable package MediumLiq | HW or CHW medium | |
| Bus | bus | Control bus |
| Bus | bus1 | Control bus |
| Bus | bus2 | Control bus |
| Bus | weaBus | Weather data bus |
| Bus | bus3 | Control bus |
| Bus | bus4 | Control bus |
Modelica definition
model Coils "Validation model for coil components"
extends Modelica.Icons.Example;
replaceable package MediumAir=Buildings.Media.Air
constrainedby Modelica.Media.Interfaces.PartialMedium
"Air medium";
replaceable package MediumLiq=Buildings.Media.Water
constrainedby Modelica.Media.Interfaces.PartialMedium
"HW or CHW medium";
parameter Modelica.Fluid.Types.Dynamics energyDynamics=
Modelica.Fluid.Types.Dynamics.FixedInitial
"Type of energy balance: dynamic (3 initialization options) or steady state";
Fluid.Sources.Boundary_pT bouAirEntCoo(
redeclare final package Medium = MediumAir,
X={coiCoo.dat.wAirEnt_nominal/(1 + coiCoo.dat.wAirEnt_nominal),1 - coiCoo.dat.wAirEnt_nominal
/(1 + coiCoo.dat.wAirEnt_nominal)},
p=bouAirLvg.p + coiCoo.dat.dpAir_nominal,
T=coiCoo.dat.TAirEnt_nominal,
nPorts=2) "Boundary conditions for entering air";
Fluid.Sources.Boundary_pT bouChiWatEnt(
redeclare final package Medium = MediumLiq,
p=bouLiqLvg.p + coiCoo.dat.dpWat_nominal + coiCoo.dat.dpValve_nominal,
T=coiCoo.dat.TWatEnt_nominal,
nPorts=1) "Boundary conditions for entering CHW";
Fluid.Sources.Boundary_pT bouLiqLvg(
redeclare final package Medium =MediumLiq, nPorts=2)
"Boundary conditions for leaving liquid";
Fluid.Sources.Boundary_pT bouAirLvg(
redeclare final package Medium =MediumAir, nPorts=6) "Boundary conditions for leaving air";
Buildings.Templates.Components.Coils.WaterBasedCooling coiCoo(
redeclare final package MediumAir=MediumAir,
redeclare final package MediumChiWat=MediumLiq,
dat(
mAir_flow_nominal=1,
dpAir_nominal=200,
mWat_flow_nominal=1,
dpWat_nominal=2E4,
dpValve_nominal=coiCoo.dat.dpWat_nominal,
cap_nominal=-5E4,
TWatEnt_nominal=280.15,
TAirEnt_nominal=308.15,
wAirEnt_nominal=0.017),
final energyDynamics=energyDynamics,
val(y_start=0)) "Water-based cooling coil";
Interfaces.Bus bus "Control bus";
Buildings.Controls.OBC.CDL.Reals.Sources.Ramp y(height=1,
duration=10) "Coil/valve control signal";
Buildings.Templates.Components.Coils.WaterBasedHeating coiHea(
redeclare final package MediumAir = MediumAir,
redeclare final package MediumHeaWat=MediumLiq,
dat(
mAir_flow_nominal=1,
dpAir_nominal=200,
mWat_flow_nominal=1,
dpWat_nominal=2E4,
dpValve_nominal=coiCoo.dat.dpWat_nominal,
cap_nominal=5E4,
TWatEnt_nominal=323.15,
TAirEnt_nominal=263.15),
final energyDynamics=energyDynamics,
val(y_start=0)) "Water-based heating";
Interfaces.Bus bus1 "Control bus";
Fluid.Sources.Boundary_pT bouAirEntHea(
redeclare final package Medium = MediumAir,
p=bouAirLvg.p + coiHea.dat.dpAir_nominal,
T=coiHea.dat.TAirEnt_nominal,
nPorts=2) "Boundary conditions for entering air";
Fluid.Sources.Boundary_pT bouHeaWatEnt(
redeclare final package Medium = MediumLiq,
p=bouLiqLvg.p + coiHea.dat.dpWat_nominal + coiHea.dat.dpValve_nominal,
T=coiHea.dat.TWatEnt_nominal,
nPorts=1) "Boundary conditions for entering HW";
Buildings.Templates.Components.Coils.ElectricHeating coiEle(
redeclare final package MediumAir = MediumAir,
dat(
mAir_flow_nominal=1,
dpAir_nominal=200,
cap_nominal=5E4),
final energyDynamics=energyDynamics) "Electric heating";
Interfaces.Bus bus2 "Control bus";
Buildings.Templates.Components.Coils.EvaporatorVariableSpeed coiEva(
redeclare final package MediumAir = MediumAir,
dat(dpAir_nominal=200),
final energyDynamics=energyDynamics) "Variable speed evaporator coil";
BoundaryConditions.WeatherData.Bus weaBus "Weather data bus";
Interfaces.Bus bus3 "Control bus";
Buildings.Controls.OBC.CDL.Reals.Sources.Constant TOut(
k=coiEva.dat.datCoi.sta[1].nomVal.TConIn_nominal)
"Outdoor temperature";
Buildings.Controls.OBC.CDL.Reals.Sources.Constant XOut(k=0.015)
"Water mass fraction in outdoor air";
Buildings.Utilities.Psychrometrics.TWetBul_TDryBulXi wetBul(redeclare final
package Medium = MediumAir) "Compute wet bulb temperature";
Buildings.Controls.OBC.CDL.Reals.Sources.Constant pOut(k=101325)
"Outdoor pressure";
Fluid.Sources.Boundary_pT bouAirEntCoo1(
redeclare final package Medium = MediumAir,
use_Xi_in=true,
p=bouAirLvg.p + coiEva.dat.dpAir_nominal,
T=coiEva.dat.datCoi.sta[1].nomVal.TEvaIn_nominal,
nPorts=2) "Boundary conditions for entering air";
Buildings.Utilities.Psychrometrics.X_pTphi x_pTphi(use_p_in=false)
"Compute wet bulb temperature";
Buildings.Controls.OBC.CDL.Reals.Sources.Constant TAirEnt(k=coiEva.dat.datCoi.sta[
1].nomVal.TEvaIn_nominal) "Entering air temperature";
Buildings.Controls.OBC.CDL.Reals.Sources.Constant phiAirEnt(k=coiEva.dat.datCoi.sta[
1].nomVal.phiIn_nominal) "Enetring air relative humidity";
Buildings.Templates.Components.Coils.EvaporatorMultiStage coiMul(
redeclare final package MediumAir = MediumAir,
dat(
redeclare Buildings.Fluid.DXSystems.Cooling.AirSource.Data.DoubleSpeed.Lennox_SCA240H4B
datCoi,
dpAir_nominal=200),
final energyDynamics=energyDynamics) "Multiple stage evaporator coil";
Buildings.Controls.OBC.CDL.Integers.Sources.TimeTable y1(
table=[0,0; 1,1; 2,2],
timeScale=50,
period=200) "Coil/valve control signal";
Interfaces.Bus bus4 "Control bus";
Fluid.FixedResistances.PressureDrop res(
redeclare final package Medium = MediumAir,
final m_flow_nominal=coiCoo.dat.mAir_flow_nominal,
final dp_nominal=coiCoo.dat.dpAir_nominal) "Flow resistance";
Buildings.Templates.Components.Coils.None non(
redeclare final package MediumAir =MediumAir) "No coilamper";
equation
connect(bouAirEntCoo.ports[1], coiCoo.port_a);
connect(coiCoo.port_b, bouAirLvg.ports[1]);
connect(bouChiWatEnt.ports[1], coiCoo.port_aSou);
connect(bouLiqLvg.ports[1], coiCoo.port_bSou);
connect(y.y, bus.y);
connect(bus, coiCoo.bus);
connect(coiHea.bus, bus1);
connect(y.y, bus1.y);
connect(bouAirEntHea.ports[1], coiHea.port_a);
connect(coiHea.port_b, bouAirLvg.ports[2]);
connect(bouHeaWatEnt.ports[1], coiHea.port_aSou);
connect(coiHea.port_bSou, bouLiqLvg.ports[2]);
connect(bouAirEntHea.ports[2], coiEle.port_a);
connect(coiEle.bus, bus2);
connect(coiEle.port_b, bouAirLvg.ports[3]);
connect(y.y, bus2.y);
connect(coiEva.port_b, bouAirLvg.ports[4]);
connect(bus3, coiEva.bus);
connect(weaBus, coiEva.busWea);
connect(y.y, bus3.y);
connect(TOut.y, weaBus.TDryBul);
connect(TOut.y, wetBul.TDryBul);
connect(pOut.y, wetBul.p);
connect(wetBul.TWetBul, weaBus.TWetBul);
connect(XOut.y, wetBul.Xi[1]);
connect(bouAirEntCoo1.ports[1], coiEva.port_a);
connect(phiAirEnt.y, x_pTphi.phi);
connect(TAirEnt.y, x_pTphi.T);
connect(x_pTphi.X[1], bouAirEntCoo1.Xi_in[1]);
connect(coiMul.port_b, bouAirLvg.ports[5]);
connect(bouAirEntCoo1.ports[2], coiMul.port_a);
connect(weaBus, coiMul.busWea);
connect(y1.y[1], bus4.y);
connect(coiMul.bus, bus4);
connect(res.port_b, non.port_a);
connect(non.port_b, bouAirLvg.ports[6]);
connect(bouAirEntCoo.ports[2], res.port_a);
end Coils;
Buildings.Templates.Components.Validation.Dampers
Validation model for damper components
Information
This model validates the various configurations of the model Buildings.Templates.Components.Actuators.Damper by exposing this model to a fixed pressure difference and a control signal varying from 0 to 1.
Extends from Modelica.Icons.Example (Icon for runnable examples).
Parameters
| Type | Name | Default | Description |
|---|---|---|---|
| replaceable package MediumAir | Buildings.Media.Air | Air medium | |
Connectors
| Type | Name | Description |
|---|---|---|
| replaceable package MediumAir | Air medium | |
| Bus | bus | Control bus |
| Bus | bus1 | Control bus |
| Bus | bus2 | Control bus |
Modelica definition
model Dampers "Validation model for damper components"
extends Modelica.Icons.Example;
replaceable package MediumAir=Buildings.Media.Air
constrainedby Modelica.Media.Interfaces.PartialMedium
"Air medium";
Fluid.Sources.Boundary_pT bouAirEnt(
redeclare final package Medium = MediumAir,
p=bouAirLvg.p + mod.dat.dp_nominal,
nPorts=4) "Boundary conditions for entering air";
Fluid.Sources.Boundary_pT bouAirLvg(
redeclare final package Medium =MediumAir, nPorts=4)
"Boundary conditions for leaving air";
Buildings.Templates.Components.Actuators.Damper mod(
final typ=Buildings.Templates.Components.Types.Damper.Modulating,
y_start=0,
redeclare final package Medium = MediumAir,
dat(m_flow_nominal=1,
dp_nominal=50))
"Modulating damper";
Interfaces.Bus bus
"Control bus";
Buildings.Controls.OBC.CDL.Reals.Sources.Ramp y(height=1,
duration=10) "Damper control signal";
Buildings.Templates.Components.Actuators.Damper pre(
final typ=Buildings.Templates.Components.Types.Damper.PressureIndependent,
y_start=0,
redeclare final package Medium = MediumAir,
dat(m_flow_nominal=1, dp_nominal=50))
"Pressure independent damper";
Interfaces.Bus bus1
"Control bus";
Buildings.Templates.Components.Actuators.Damper two(
final typ=Buildings.Templates.Components.Types.Damper.TwoPosition,
y_start=0,
redeclare final package Medium = MediumAir,
dat(m_flow_nominal=1, dp_nominal=50)) "Two-position damper";
Interfaces.Bus bus2
"Control bus";
Buildings.Controls.OBC.CDL.Logical.Sources.TimeTable y1(
table=[0,0; 1,1],
timeScale=10,
period=200) "Damper control signal";
Buildings.Templates.Components.Actuators.Damper non(
final typ=Buildings.Templates.Components.Types.Damper.None,
redeclare final package Medium = MediumAir)
"No damper";
Fluid.FixedResistances.PressureDrop res(
redeclare final package Medium = MediumAir,
final m_flow_nominal=mod.m_flow_nominal,
final dp_nominal=mod.dp_nominal) "Flow resistance";
equation
connect(bouAirEnt.ports[1], mod.port_a);
connect(mod.port_b, bouAirLvg.ports[1]);
connect(y.y, bus.y);
connect(bus, mod.bus);
connect(bouAirEnt.ports[2], pre.port_a);
connect(pre.port_b, bouAirLvg.ports[2]);
connect(bus1, pre.bus);
connect(y.y, bus1.y);
connect(bouAirEnt.ports[3], two.port_a);
connect(two.port_b, bouAirLvg.ports[3]);
connect(bus2, two.bus);
connect(y1.y[1], bus2.y1);
connect(non.port_b, bouAirLvg.ports[4]);
connect(bouAirEnt.ports[4], res.port_a);
connect(res.port_b, non.port_a);
end Dampers;
Buildings.Templates.Components.Validation.Fans
Validation model for fans components
Information
This model validates the models within Buildings.Templates.Components.Fans by exposing them to a control signal varying from 0 to 1 and connecting them to an air loop with a fixed flow resistance, which is sized based on the nominal operating point of the fan model.
Extends from Modelica.Icons.Example (Icon for runnable examples).
Parameters
| Type | Name | Default | Description |
|---|---|---|---|
| replaceable package MediumAir | Buildings.Media.Air | Air medium | |
| Dynamics | |||
| Conservation equations | |||
| Dynamics | energyDynamics | Modelica.Fluid.Types.Dynamic... | Type of energy balance: dynamic (3 initialization options) or steady state |
Connectors
| Type | Name | Description |
|---|---|---|
| replaceable package MediumAir | Air medium | |
| Bus | bus | Control bus |
| Bus | bus1 | Control bus |
| Bus | bus2 | Control bus |
Modelica definition
model Fans "Validation model for fans components"
extends Modelica.Icons.Example;
replaceable package MediumAir=Buildings.Media.Air
constrainedby Modelica.Media.Interfaces.PartialMedium
"Air medium";
parameter Modelica.Fluid.Types.Dynamics energyDynamics=
Modelica.Fluid.Types.Dynamics.FixedInitial
"Type of energy balance: dynamic (3 initialization options) or steady state";
Fluid.Sources.Boundary_pT bou(
redeclare final package Medium = MediumAir,
nPorts=8) "Boundary conditions";
Buildings.Templates.Components.Fans.ArrayVariable arr(
redeclare final package Medium=MediumAir,
have_senFlo=true,
final energyDynamics=energyDynamics,
dat(m_flow_nominal=1, dp_nominal=1000),
nFan=4)
"Fan array";
Fluid.FixedResistances.PressureDrop res(
redeclare final package Medium=MediumAir,
final m_flow_nominal=arr.dat.m_flow_nominal,
final dp_nominal=arr.dat.dp_nominal)
"Ducts and coils equivalent flow resistance";
Buildings.Controls.OBC.CDL.Reals.Sources.Ramp y(height=1, duration=10)
"Fan control signal";
Interfaces.Bus bus "Control bus";
Buildings.Controls.OBC.CDL.Logical.Sources.TimeTable y1(
table=[0,0; 1,1],
timeScale=10,
period=100) "Fan start/stop signal";
Buildings.Templates.Components.Fans.SingleVariable var(
redeclare final package Medium=MediumAir,
have_senFlo=true,
final energyDynamics=energyDynamics,
dat(m_flow_nominal=1, dp_nominal=1000)) "Variable speed fan";
Interfaces.Bus bus1 "Control bus";
Buildings.Templates.Components.Fans.SingleConstant cst(
redeclare final package Medium=MediumAir,
have_senFlo=true,
final energyDynamics=energyDynamics,
dat(m_flow_nominal=1, dp_nominal=1000)) "Constant speed fan";
Fluid.FixedResistances.PressureDrop res1(
redeclare final package Medium = MediumAir,
final m_flow_nominal=cst.dat.m_flow_nominal,
final dp_nominal=cst.dat.dp_nominal)
"Ducts and coils equivalent flow resistance";
Fluid.FixedResistances.PressureDrop res2(
redeclare final package Medium = MediumAir,
final m_flow_nominal=var.dat.m_flow_nominal,
final dp_nominal=var.dat.dp_nominal)
"Ducts and coils equivalent flow resistance";
Interfaces.Bus bus2
"Control bus";
Buildings.Templates.Components.Fans.None non(
redeclare final package Medium = MediumAir)
"No fan";
Fluid.FixedResistances.PressureDrop res3(
redeclare final package Medium = MediumAir,
final m_flow_nominal=1,
final dp_nominal=1000)
"Ducts and coils equivalent flow resistance";
equation
connect(bou.ports[1], arr.port_a);
connect(res.port_b, bou.ports[2]);
connect(arr.port_b, res.port_a);
connect(y.y, bus.y);
connect(bus, arr.bus);
connect(y1.y[1], bus1.y1);
connect(cst.port_b, res1.port_a);
connect(bou.ports[3], cst.port_a);
connect(res1.port_b, bou.ports[4]);
connect(res2.port_b, bou.ports[5]);
connect(bou.ports[6], var.port_a);
connect(var.port_b, res2.port_a);
connect(bus2, var.bus);
connect(bus1, cst.bus);
connect(y.y, bus2.y);
connect(bou.ports[7], non.port_a);
connect(non.port_b, res3.port_a);
connect(res3.port_b, bou.ports[8]);
connect(y1.y[1], bus2.y1);
connect(y1.y[1], bus.y1);
end Fans;
Buildings.Templates.Components.Validation.PumpMultipleRecord
Validation model for parameter propagation with the multiple-pump record
Information
This model validates the parameter propagation within the record class Buildings.Templates.Components.Data.PumpMultiple.
The instance datDef illustrates the default pressure curve
assignment based on the design parameters.
The instance datRed illustrates the modification of the
pressure curve by redeclaring the subrecord per.
In this case, all elements per[i] are equal.
The instances datAss and datPre illustrate
the modification of the pressure curve by assigning either the whole
subrecord per or its component per.pressure.
This allows assigning different pressure curves to the elements per[i].
Extends from Modelica.Icons.Example (Icon for runnable examples).
Parameters
| Type | Name | Default | Description |
|---|---|---|---|
| replaceable package Medium | Buildings.Media.Water | Fluid medium | |
| MassFlowRate | m_flow_nominal[nPum] | {1,2} | Mass flow rate - Each pump [kg/s] |
| PressureDifference | dp_nominal[nPum] | {1,2} .* 1E4 | Total pressure rise - Each pump [Pa] |
| PumpMultiple | datDef | datDef(final typ=Buildings.T... | Parameter record - Default bindings for subrecord per |
| PumpMultiple | datRed | datRed(final typ=Buildings.T... | Parameter record - Redeclaration of subrecord per |
| Stratos80slash1to12 | per1 | ||
| Stratos50slash1to12 | per2 | ||
| PumpMultiple | datAss | datAss(final typ=Buildings.T... | Parameter record - Assignment of subrecord per |
| PumpMultiple | datPre | datPre(final typ=Buildings.T... | Parameter record - Assignment of pressure inside the subrecord per |
| Configuration | |||
| Integer | nPum | 2 | Number of pumps |
Connectors
| Type | Name | Description |
|---|---|---|
| replaceable package Medium | Fluid medium | |
Modelica definition
model PumpMultipleRecord "Validation model for parameter propagation with the multiple-pump record"
extends Modelica.Icons.Example;
replaceable package Medium=Buildings.Media.Water
constrainedby Modelica.Media.Interfaces.PartialMedium
"Fluid medium";
parameter Integer nPum(
final min=0,
start=1)=2
"Number of pumps";
parameter Modelica.Units.SI.MassFlowRate m_flow_nominal[nPum](
each start=1,
each final min=0)={1, 2}
"Mass flow rate - Each pump";
final parameter Modelica.Units.SI.VolumeFlowRate V_flow_nominal[nPum]=
m_flow_nominal ./ datDef.rho_default
"Mass flow rate - Each pump";
parameter Modelica.Units.SI.PressureDifference dp_nominal[nPum](
each start=0,
each final min=0)={1, 2} .* 1E4
"Total pressure rise - Each pump";
parameter Buildings.Templates.Components.Data.PumpMultiple datDef(
final typ=Buildings.Templates.Components.Types.Pump.Multiple,
final nPum=nPum,
final m_flow_nominal=m_flow_nominal,
final dp_nominal=dp_nominal)
"Parameter record - Default bindings for subrecord per";
parameter Buildings.Templates.Components.Data.PumpMultiple datRed(
final typ=Buildings.Templates.Components.Types.Pump.Multiple,
final nPum=nPum,
final m_flow_nominal=m_flow_nominal,
final dp_nominal=dp_nominal,
redeclare Buildings.Fluid.Movers.Data.Pumps.Wilo.Stratos80slash1to12 per)
"Parameter record - Redeclaration of subrecord per";
parameter Buildings.Fluid.Movers.Data.Pumps.Wilo.Stratos80slash1to12 per1;
parameter Buildings.Fluid.Movers.Data.Pumps.Wilo.Stratos50slash1to12 per2;
parameter Buildings.Templates.Components.Data.PumpMultiple datAss(
final typ=Buildings.Templates.Components.Types.Pump.Multiple,
final nPum=nPum,
final m_flow_nominal=m_flow_nominal,
final dp_nominal=dp_nominal,
per={per1, per2})
"Parameter record - Assignment of subrecord per";
parameter Buildings.Templates.Components.Data.PumpMultiple datPre(
final typ=Buildings.Templates.Components.Types.Pump.Multiple,
final nPum=nPum,
final m_flow_nominal=m_flow_nominal,
final dp_nominal=dp_nominal,
per(pressure(
V_flow={{0, 2, 4} * m_flow_nominal[i] / datPre.rho_default for i in 1:nPum},
dp={{2, 1.5, 0.8} * dp_nominal[i] for i in 1:nPum})))
"Parameter record - Assignment of pressure inside the subrecord per";
end PumpMultipleRecord;
Buildings.Templates.Components.Validation.Pumps
Validation model for pump components
Information
This model validates the models within
Buildings.Templates.Components.Pumps
by connecting each pump component to a water loop with a
fixed flow resistance, which
is sized based on the pump's nominal operating point.
Two identical parallel pumps are modeled with either
one instance of
Buildings.Templates.Components.Pumps.Multiple
or two instances of
Buildings.Templates.Components.Pumps.Single.
The multiple pump component is configured to represent
variable speed pumps with dedicated speed command signals
(component pumMulDed),
variable speed pumps with common speed command
signal (component pumMul) or constant speed pumps
(component pumMulCst).
The single pump components (pum1 and pum2)
are configured to represent variable speed pumps.
Extends from Modelica.Icons.Example (Icon for runnable examples).
Parameters
| Type | Name | Default | Description |
|---|---|---|---|
| replaceable package Medium | Buildings.Media.Water | Liquid medium | |
| PumpSingle | datPum | datPum(final typ=pum1.typ, m... | Single pump parameters |
| PumpMultiple | datPumMul | datPumMul(final typ=pumMul.t... | Multiple pump parameters |
| Dynamics | |||
| Conservation equations | |||
| Dynamics | energyDynamics | Modelica.Fluid.Types.Dynamic... | Type of energy balance: dynamic (3 initialization options) or steady state |
Connectors
| Type | Name | Description |
|---|---|---|
| replaceable package Medium | Liquid medium | |
Modelica definition
model Pumps "Validation model for pump components"
extends Modelica.Icons.Example;
replaceable package Medium=Buildings.Media.Water
constrainedby Modelica.Media.Interfaces.PartialMedium
"Liquid medium";
parameter Data.PumpSingle datPum(
final typ=pum1.typ,
m_flow_nominal=1,
dp_nominal=1E5) "Single pump parameters";
parameter Data.PumpMultiple datPumMul(
final typ=pumMul.typ,
final nPum=pumMul.nPum,
m_flow_nominal=fill(1, datPumMul.nPum),
dp_nominal=fill(1E5, datPumMul.nPum))
"Multiple pump parameters";
parameter Modelica.Fluid.Types.Dynamics energyDynamics=
Modelica.Fluid.Types.Dynamics.FixedInitial
"Type of energy balance: dynamic (3 initialization options) or steady state";
Buildings.Templates.Components.Pumps.Multiple pumMul(
final energyDynamics=energyDynamics,
redeclare final package Medium=Medium,
nPum=2,
final dat=datPumMul)
"Two variable speed pumps in parallel with common speed command signal";
Buildings.Templates.Components.Pumps.Single pum1(
final energyDynamics=energyDynamics,
redeclare final package Medium = Medium,
final dat=datPum) "Single variable speed pump";
Buildings.Templates.Components.Pumps.Single pum2(
final energyDynamics=energyDynamics,
redeclare final package Medium=Medium,
final dat=datPum) "Single variable speed pump";
Fluid.FixedResistances.Junction junInl(
redeclare final package Medium=Medium,
final energyDynamics=energyDynamics,
final m_flow_nominal=sum(datPumMul.m_flow_nominal) * {1,-1,-1},
final dp_nominal=fill(0,3))
"Fluid junction";
Fluid.FixedResistances.Junction junOut(
redeclare final package Medium=Medium,
final energyDynamics=energyDynamics,
final m_flow_nominal=sum(datPumMul.m_flow_nominal) * {1,-1,1},
final dp_nominal=fill(0,3))
"Fluid junction";
Fluid.FixedResistances.PressureDrop res(
redeclare final package Medium = Medium,
final m_flow_nominal=pum1.m_flow_nominal + pum2.m_flow_nominal,
final dp_nominal=pum1.dp_nominal - pum1.dpValChe_nominal)
"Fixed flow resistance";
Fluid.FixedResistances.Junction junInl1(
redeclare final package Medium = Medium,
final energyDynamics=energyDynamics,
final m_flow_nominal=sum(datPumMul.m_flow_nominal)*{1,-1,-1},
final dp_nominal=fill(0, 3))
"Fluid junction";
Fluid.FixedResistances.Junction junOut1(
redeclare final package Medium = Medium,
final energyDynamics=energyDynamics,
final m_flow_nominal=sum(datPumMul.m_flow_nominal)*{1,-1,1},
final dp_nominal=fill(0, 3))
"Fluid junction";
Fluid.FixedResistances.PressureDrop resMul(
redeclare final package Medium = Medium,
final m_flow_nominal=sum(pumMul.m_flow_nominal),
final dp_nominal=max(pumMul.dp_nominal .- pumMul.dpValChe_nominal))
"Fixed flow resistance";
Buildings.Controls.OBC.CDL.Logical.Sources.TimeTable y1(
table=[
0, 0, 0;
1, 1, 0;
2, 1, 1;
3, 0, 0],
timeScale=100,
period=300) "Pump enable signal";
Buildings.Controls.OBC.CDL.Reals.Sources.Constant y(k=1) "Pump speed command";
Fluid.Sources.Boundary_pT bou(
redeclare final package Medium=Medium, nPorts=1)
"Pressure boundary condition";
Fluid.Sources.Boundary_pT bou1(redeclare final package Medium = Medium,
nPorts=1)
"Pressure boundary condition";
Buildings.Templates.Components.Pumps.Multiple pumMulCst(
have_var=false,
final energyDynamics=energyDynamics,
redeclare final package Medium = Medium,
nPum=2,
final dat=datPumMul) "Two constant speed pumps in parallel";
Fluid.FixedResistances.Junction junInl2(
redeclare final package Medium = Medium,
final energyDynamics=energyDynamics,
final m_flow_nominal=sum(datPumMul.m_flow_nominal)*{1,-1,-1},
final dp_nominal=fill(0, 3))
"Fluid junction";
Fluid.FixedResistances.Junction junOut2(
redeclare final package Medium = Medium,
final energyDynamics=energyDynamics,
final m_flow_nominal=sum(datPumMul.m_flow_nominal)*{1,-1,1},
final dp_nominal=fill(0, 3))
"Fluid junction";
Fluid.FixedResistances.PressureDrop resMulCst(
redeclare final package Medium = Medium,
final m_flow_nominal=sum(pumMulCst.m_flow_nominal),
final dp_nominal=max(pumMulCst.dp_nominal .- pumMulCst.dpValChe_nominal))
"Fixed flow resistance";
Fluid.Sources.Boundary_pT bou2(redeclare final package Medium = Medium,
nPorts=1)
"Pressure boundary condition";
Buildings.Templates.Components.Pumps.Multiple pumMulDed(
have_varCom=false,
final energyDynamics=energyDynamics,
redeclare final package Medium = Medium,
nPum=2,
final dat=datPumMul)
"Two variable speed pumps in parallel with dedicated speed command signal";
Fluid.FixedResistances.Junction junInl3(
redeclare final package Medium = Medium,
final energyDynamics=energyDynamics,
final m_flow_nominal=sum(datPumMul.m_flow_nominal)*{1,-1,-1},
final dp_nominal=fill(0, 3))
"Fluid junction";
Fluid.FixedResistances.Junction junOut3(
redeclare final package Medium = Medium,
final energyDynamics=energyDynamics,
final m_flow_nominal=sum(datPumMul.m_flow_nominal)*{1,-1,1},
final dp_nominal=fill(0, 3))
"Fluid junction";
Fluid.FixedResistances.PressureDrop resMulDed(
redeclare final package Medium = Medium,
final m_flow_nominal=sum(pumMulDed.m_flow_nominal),
final dp_nominal=max(pumMulDed.dp_nominal .- pumMulDed.dpValChe_nominal))
"Fixed flow resistance";
Fluid.Sources.Boundary_pT bou3(redeclare final package Medium = Medium,
nPorts=1)
"Pressure boundary condition";
Buildings.Controls.OBC.CDL.Reals.Sources.Constant yDed[pumMulDed.nPum](each k
=1) "Pump speed command";
protected
Interfaces.Bus bus "Pump control bus";
Interfaces.Bus bus1 "Pump control bus";
Interfaces.Bus bus2 "Pump control bus";
Interfaces.Bus bus3 "Pump control bus";
Interfaces.Bus bus4 "Pump control bus";
equation
connect(pum1.port_b, junOut.port_1);
connect(junInl.port_2, pum1.port_a);
connect(junInl.port_3, pum2.port_a);
connect(pum2.port_b, junOut.port_3);
connect(junOut.port_2, res.port_a);
connect(res.port_b, junInl.port_1);
connect(junOut1.port_2, resMul.port_a);
connect(junInl1.port_2, pumMul.ports_a[1]);
connect(pumMul.ports_b[1], junOut1.port_1);
connect(pumMul.ports_b[2], junOut1.port_3);
connect(junInl1.port_3, pumMul.ports_a[2]);
connect(resMul.port_b, junInl1.port_1);
connect(bus1, pum2.bus);
connect(y1.y[2], bus1.y1);
connect(y.y, bus1.y);
connect(y1.y[1], bus.y1);
connect(y.y, bus.y);
connect(bus, pum1.bus);
connect(bus2, pumMul.bus);
connect(y1.y[1:2], bus2.y1);
connect(y.y, bus2.y);
connect(bou.ports[1], junInl.port_1);
connect(bou1.ports[1], junInl1.port_1);
connect(junOut2.port_2, resMulCst.port_a);
connect(junInl2.port_2, pumMulCst.ports_a[1]);
connect(pumMulCst.ports_b[1], junOut2.port_1);
connect(pumMulCst.ports_b[2], junOut2.port_3);
connect(junInl2.port_3, pumMulCst.ports_a[2]);
connect(resMulCst.port_b, junInl2.port_1);
connect(bus3, pumMulCst.bus);
connect(bou2.ports[1],junInl2. port_1);
connect(y1.y[1:2], bus3.y1);
connect(junOut3.port_2, resMulDed.port_a);
connect(junInl3.port_2, pumMulDed.ports_a[1]);
connect(pumMulDed.ports_b[1], junOut3.port_1);
connect(pumMulDed.ports_b[2], junOut3.port_3);
connect(junInl3.port_3, pumMulDed.ports_a[2]);
connect(resMulDed.port_b, junInl3.port_1);
connect(bus4, pumMulDed.bus);
connect(bou3.ports[1],junInl3. port_1);
connect(y1.y, bus4.y1);
connect(yDed.y, bus4.y);
end Pumps;
Buildings.Templates.Components.Validation.Routing
Validation model for routing components
Information
This model validates the models within Buildings.Templates.Components.Routing by exposing them to a fixed pressure difference.
Extends from Modelica.Icons.Example (Icon for runnable examples).
Parameters
| Type | Name | Default | Description |
|---|---|---|---|
| replaceable package Medium | Buildings.Media.Water | Medium | |
| Dynamics | |||
| Conservation equations | |||
| Dynamics | energyDynamics | Modelica.Fluid.Types.Dynamic... | Type of energy balance: dynamic (3 initialization options) or steady state |
Connectors
| Type | Name | Description |
|---|---|---|
| replaceable package Medium | Medium | |
Modelica definition
model Routing "Validation model for routing components"
extends Modelica.Icons.Example;
replaceable package Medium=Buildings.Media.Water
constrainedby Modelica.Media.Interfaces.PartialMedium
"Medium";
parameter Modelica.Fluid.Types.Dynamics energyDynamics=
Modelica.Fluid.Types.Dynamics.FixedInitial
"Type of energy balance: dynamic (3 initialization options) or steady state";
Fluid.Sources.Boundary_pT bouLiqEnt(
redeclare final package Medium = Medium,
p=bouLiqLvg.p + min(res.dp_nominal),
nPorts=3) "Boundary conditions for entering liquid";
Fluid.Sources.Boundary_pT bouLiqLvg(redeclare final package Medium = Medium,
nPorts=3)
"Boundary conditions for leaving liquid";
Fluid.FixedResistances.PressureDrop res[3](
redeclare final package Medium = Medium,
each m_flow_nominal=1,
each dp_nominal=1000) "Flow resistance";
Buildings.Templates.Components.Routing.MultipleToMultiple mulMul(
redeclare final package Medium = Medium,
final energyDynamics=energyDynamics,
nPorts_a=3,
m_flow_nominal=3) "Multiple to multiple without common leg";
Fluid.Sources.Boundary_pT bouLiqEnt1(
redeclare final package Medium = Medium,
p=bouLiqLvg.p + min(res1.dp_nominal) + min(res2.dp_nominal),
nPorts=3) "Boundary conditions for entering liquid";
Fluid.Sources.Boundary_pT bouLiqLvg1(redeclare final package Medium = Medium,
nPorts=3)
"Boundary conditions for leaving liquid";
Fluid.FixedResistances.PressureDrop res1
[3](
redeclare final package Medium = Medium,
each m_flow_nominal=1,
each dp_nominal=1000) "Flow resistance";
Buildings.Templates.Components.Routing.MultipleToMultiple mulMulCom(
redeclare final package Medium = Medium,
final energyDynamics=energyDynamics,
nPorts_a=3,
have_comLeg=true,
m_flow_nominal=3) "Multiple to multiple with common leg";
Fluid.FixedResistances.PressureDrop res2[3](
redeclare final package Medium = Medium,
each m_flow_nominal=1,
each dp_nominal=1000) "Flow resistance";
Fluid.Sources.Boundary_pT bouLiqEnt2(
redeclare final package Medium = Medium,
p=bouLiqLvg.p + min(res3.dp_nominal),
nPorts=3) "Boundary conditions for entering liquid";
Fluid.Sources.Boundary_pT bouLiqLvg2(redeclare final package Medium = Medium,
nPorts=1)
"Boundary conditions for leaving liquid";
Fluid.FixedResistances.PressureDrop res3
[3](
redeclare final package Medium = Medium,
each m_flow_nominal=1,
each dp_nominal=1000) "Flow resistance";
Buildings.Templates.Components.Routing.MultipleToSingle mulSin(
redeclare final package Medium = Medium,
final energyDynamics=energyDynamics,
nPorts=3,
m_flow_nominal=3) "Multiple to single";
Fluid.Sources.Boundary_pT bouLiqEnt3(
redeclare final package Medium = Medium,
p=bouLiqLvg.p + min(res5.dp_nominal),
nPorts=1) "Boundary conditions for entering liquid";
Fluid.Sources.Boundary_pT bouLiqLvg3(redeclare final package Medium = Medium,
nPorts=3)
"Boundary conditions for leaving liquid";
Buildings.Templates.Components.Routing.SingleToMultiple sinMul(
redeclare final package Medium = Medium,
final energyDynamics=energyDynamics,
nPorts=3,
m_flow_nominal=3) "Single to multiple";
Fluid.FixedResistances.PressureDrop res5[3](
redeclare final package Medium = Medium,
each m_flow_nominal=1,
each dp_nominal=1000) "Flow resistance";
Fluid.Sources.Boundary_pT bouLiqEnt4(
redeclare final package Medium = Medium,
p=bouLiqLvg.p + res4.dp_nominal,
nPorts=1) "Boundary conditions for entering liquid";
Fluid.Sources.Boundary_pT bouLiqLvg4(redeclare final package Medium = Medium,
nPorts=1)
"Boundary conditions for leaving liquid";
Buildings.Templates.Components.Routing.PassThroughFluid pas(redeclare final
package Medium = Medium) "Pass through";
Fluid.FixedResistances.PressureDrop res4(
redeclare final package Medium = Medium,
m_flow_nominal=1,
dp_nominal=1000) "Flow resistance";
equation
connect(res.port_b, mulMul.ports_a);
connect(mulMul.ports_b, bouLiqLvg.ports);
connect(bouLiqEnt.ports, res.port_a);
connect(res1.port_b, mulMulCom.ports_a);
connect(bouLiqEnt1.ports, res1.port_a);
connect(mulMulCom.ports_b, res2.port_a);
connect(res2.port_b, bouLiqLvg1.ports);
connect(res3.port_b, mulSin.ports_a);
connect(bouLiqEnt2.ports,res3. port_a);
connect(mulSin.port_b, bouLiqLvg2.ports[1]);
connect(bouLiqEnt3.ports[1], sinMul.port_a);
connect(sinMul.ports_b, res5.port_a);
connect(res5.port_b, bouLiqLvg3.ports);
connect(pas.port_b, bouLiqLvg4.ports[1]);
connect(bouLiqEnt4.ports[1], res4.port_a);
connect(res4.port_b, pas.port_a);
end Routing;
Buildings.Templates.Components.Validation.Sensors
Validation model for sensor components
Information
This model validates the models within Buildings.Templates.Components.Sensors.
Extends from Modelica.Icons.Example (Icon for runnable examples).
Parameters
| Type | Name | Default | Description |
|---|---|---|---|
| replaceable package MediumAir | Buildings.Media.Air | Air medium | |
Connectors
| Type | Name | Description |
|---|---|---|
| replaceable package MediumAir | Air medium | |
Modelica definition
model Sensors "Validation model for sensor components"
extends Modelica.Icons.Example;
replaceable package MediumAir=Buildings.Media.Air
constrainedby Modelica.Media.Interfaces.PartialMedium
"Air medium";
Fluid.Sources.Boundary_pT bouAirEnt(
redeclare final package Medium = MediumAir,
p=bouAirLvg.p + res.dp_nominal,
nPorts=6) "Boundary conditions for entering air";
Fluid.Sources.Boundary_pT bouAirLvg(redeclare final package Medium =
MediumAir, nPorts=6) "Boundary conditions for leaving air";
Buildings.Templates.Components.Sensors.HumidityRatio hum(redeclare final
package Medium = MediumAir, m_flow_nominal=1) "Humidity ratio";
Fluid.FixedResistances.PressureDrop res(
redeclare final package Medium = MediumAir,
final m_flow_nominal=1,
final dp_nominal=100) "Flow resistance";
Fluid.FixedResistances.PressureDrop res1(
redeclare final package Medium = MediumAir,
final m_flow_nominal=1,
final dp_nominal=100) "Flow resistance";
Buildings.Templates.Components.Sensors.SpecificEnthalpy ent(redeclare final
package Medium = MediumAir, m_flow_nominal=1) "Specific enthalpy";
Buildings.Templates.Components.Sensors.DifferentialPressure dp(redeclare
final package Medium = MediumAir) "Differential pressure";
Fluid.FixedResistances.PressureDrop res2(
redeclare final package Medium = MediumAir,
final m_flow_nominal=1,
final dp_nominal=100) "Flow resistance";
Buildings.Templates.Components.Sensors.Temperature tem(redeclare final
package Medium = MediumAir, m_flow_nominal=1) "Temperature";
Buildings.Templates.Components.Sensors.VolumeFlowRate vol(redeclare final
package Medium = MediumAir, m_flow_nominal=1,
typ=Buildings.Templates.Components.Types.SensorVolumeFlowRate.AFMS) "Volume flow rate";
Fluid.FixedResistances.PressureDrop res3(
redeclare final package Medium = MediumAir,
final m_flow_nominal=1,
final dp_nominal=100) "Flow resistance";
Buildings.Templates.Components.Sensors.DifferentialPressure noDp(redeclare
final package Medium = MediumAir, have_sen=false)
"No differential pressure sensor";
equation
connect(bouAirEnt.ports[1], res.port_a);
connect(res.port_b, hum.port_a);
connect(hum.port_b, bouAirLvg.ports[1]);
connect(res1.port_b, ent.port_a);
connect(ent.port_b, bouAirLvg.ports[2]);
connect(bouAirEnt.ports[2], res1.port_a);
connect(bouAirEnt.ports[3], dp.port_a);
connect(dp.port_b, bouAirLvg.ports[3]);
connect(res2.port_b, tem.port_a);
connect(res3.port_b, vol.port_a);
connect(tem.port_b, bouAirLvg.ports[4]);
connect(vol.port_b, bouAirLvg.ports[5]);
connect(bouAirEnt.ports[4], res2.port_a);
connect(bouAirEnt.ports[5], res3.port_a);
connect(bouAirEnt.ports[6], noDp.port_a);
connect(noDp.port_b, bouAirLvg.ports[6]);
end Sensors;
Buildings.Templates.Components.Validation.Valves
Validation model for valve components
Information
This model validates the various configurations of the model Buildings.Templates.Components.Actuators.Valve by exposing this model to a fixed pressure difference and a control signal varying from 0 to 1.
Extends from Modelica.Icons.Example (Icon for runnable examples).
Parameters
| Type | Name | Default | Description |
|---|---|---|---|
| replaceable package MediumLiq | Buildings.Media.Water | Liquid medium | |
| Dynamics | |||
| Conservation equations | |||
| Dynamics | energyDynamics | Modelica.Fluid.Types.Dynamic... | Type of energy balance: dynamic (3 initialization options) or steady state |
Connectors
| Type | Name | Description |
|---|---|---|
| replaceable package MediumLiq | Liquid medium | |
| Bus | bus | Control bus |
| Bus | bus1 | Control bus |
| Bus | bus2 | Control bus |
| Bus | bus3 | Control bus |
Modelica definition
model Valves "Validation model for valve components"
extends Modelica.Icons.Example;
replaceable package MediumLiq=Buildings.Media.Water
constrainedby Modelica.Media.Interfaces.PartialMedium
"Liquid medium";
parameter Modelica.Fluid.Types.Dynamics energyDynamics=
Modelica.Fluid.Types.Dynamics.FixedInitial
"Type of energy balance: dynamic (3 initialization options) or steady state";
Fluid.Sources.Boundary_pT bouLiqEnt(
redeclare final package Medium = MediumLiq,
p=bouLiqLvg.p + modThr.dat.dpValve_nominal + modThr.dat.dpFixed_nominal,
nPorts=7) "Boundary conditions for entering liquid";
Fluid.Sources.Boundary_pT bouLiqLvg(
redeclare final package Medium =MediumLiq, nPorts=5)
"Boundary conditions for leaving liquid";
Actuators.Valve modThr(
redeclare final package Medium = MediumLiq,
typ=Buildings.Templates.Components.Types.Valve.ThreeWayModulating,
final energyDynamics=energyDynamics,
dat(
m_flow_nominal=1,
dpValve_nominal=5000,
dpFixed_nominal=5000))
"Three-way modulating valve";
Interfaces.Bus bus
"Control bus";
Buildings.Controls.OBC.CDL.Reals.Sources.Ramp y(height=1, duration=10)
"Damper control signal";
Actuators.Valve twoThr(
redeclare final package Medium = MediumLiq,
typ=Buildings.Templates.Components.Types.Valve.ThreeWayTwoPosition,
final energyDynamics=energyDynamics,
dat(
m_flow_nominal=1,
dpValve_nominal=5000,
dpFixed_nominal=5000)) "Three-way two position valve";
Interfaces.Bus bus1
"Control bus";
Actuators.Valve modTwo(
redeclare final package Medium = MediumLiq,
typ=Buildings.Templates.Components.Types.Valve.TwoWayModulating,
final energyDynamics=energyDynamics,
dat(
m_flow_nominal=1,
dpValve_nominal=5000,
dpFixed_nominal=5000)) "Two-way modulating valve";
Interfaces.Bus bus2
"Control bus";
Buildings.Controls.OBC.CDL.Logical.Sources.TimeTable y1(
table=[0,0; 1,1],
timeScale=10,
period=200) "Damper control signal";
Actuators.Valve twoTwo(
redeclare final package Medium = MediumLiq,
typ=Buildings.Templates.Components.Types.Valve.TwoWayTwoPosition,
final energyDynamics=energyDynamics,
dat(
m_flow_nominal=1,
dpValve_nominal=5000,
dpFixed_nominal=5000)) "Two-way two-position valve";
Interfaces.Bus bus3
"Control bus";
Actuators.Valve non(
redeclare final package Medium = MediumLiq,
typ=Buildings.Templates.Components.Types.Valve.None)
"No valve";
Fluid.FixedResistances.PressureDrop res(
redeclare final package Medium = MediumLiq,
final m_flow_nominal=modTwo.m_flow_nominal,
final dp_nominal=modTwo.dpValve_nominal + modTwo.dpFixed_nominal)
"Flow resistance";
equation
connect(bouLiqEnt.ports[1], modThr.port_a);
connect(modThr.port_b,bouLiqLvg. ports[1]);
connect(y.y, bus.y);
connect(bus, modThr.bus);
connect(bouLiqEnt.ports[3], twoThr.port_a);
connect(twoThr.port_b, bouLiqLvg.ports[2]);
connect(bus1, twoThr.bus);
connect(bouLiqEnt.ports[2], modTwo.port_a);
connect(modTwo.port_b, bouLiqLvg.ports[3]);
connect(bus2, modTwo.bus);
connect(y.y, bus2.y);
connect(y1.y[1], bus1.y1);
connect(bus3, twoTwo.bus);
connect(y1.y[1],bus3. y1);
connect(bouLiqEnt.ports[4], twoTwo.port_a);
connect(twoTwo.port_b, bouLiqLvg.ports[4]);
connect(bouLiqEnt.ports[5], modThr.portByp_a);
connect(bouLiqEnt.ports[6], twoThr.portByp_a);
connect(non.port_b, bouLiqLvg.ports[5]);
connect(bouLiqEnt.ports[7], res.port_a);
connect(res.port_b, non.port_a);
end Valves;
