Buildings.Obsolete.DHC.ETS.Combined.Subsystems
Package with obsolete models for district heating and cooling sub-systems
Information
Package with obsolete models for district heating and cooling sub-systems.
Extends from Modelica.Icons.Package (Icon for standard packages).
Package Content
| Name | Description |
|---|---|
 Borefield
|
Base subsystem with geothermal borefield |
 Chiller
|
Base subsystem with heat recovery chiller |
 HeatExchanger
|
Base subsystem with district heat exchanger |
 Validation
|
Collection of validation models |
Buildings.Obsolete.DHC.ETS.Combined.Subsystems.Borefield
Base subsystem with geothermal borefield
Information
This is a model for a borefield system with a variable speed pump and a mixing valve modulated to maintain a maximum inlet temperature.
The system is controlled based on the logic described in Buildings.Obsolete.DHC.ETS.Combined.Controls.Borefield. The pump flow rate is considered proportional to the pump speed under the assumption of a constant flow resistance in the borefield loop. This assumption is justified by the connection of the loop to the buffer tanks, and by the additional assumption that the bypass branch of the mixing valve is balanced with the direct branch.
(The parameter from_dp of the valve model is set to false to
simplify the system of algebraic equations, which, in this specific case,
alleviates non-convergence issues.)
Extends from Buildings.Obsolete.BaseClasses.ObsoleteModel (Icon for classes that are obsolete and will be removed in later versions), Buildings.Fluid.Interfaces.PartialTwoPortInterface (Partial model with two ports and declaration of quantities that are used by many models).
Parameters
| Type | Name | Default | Description |
|---|---|---|---|
| replaceable package Medium | PartialMedium | Medium in the component | |
| replaceable model BorefieldType | Buildings.Fluid.Geothermal.B... | Wall heat transfer | |
| Example | datBorFie | datBorFie(conDat=Buildings.F... | Borefield parameters |
| Pressure | dpValBorFie_nominal | dp_nominal/2 | Nominal pressure drop of control valve [Pa] |
| Temperature | TBorWatEntMax | Maximum value of borefield water entering temperature [K] | |
| Real | spePumBorMin | 0.1 | Borefield pump minimum speed |
| Nominal condition | |||
| MassFlowRate | m_flow_nominal | datBorFie.conDat.mBorFie_flo... | Nominal mass flow rate [kg/s] |
| Pressure | dp_nominal | Pressure losses for the entire borefield (control valve excluded) [Pa] | |
| Assumptions | |||
| Boolean | allowFlowReversal | true | = false to simplify equations, assuming, but not enforcing, no flow reversal |
| Advanced | |||
| MassFlowRate | m_flow_small | 1E-4*abs(m_flow_nominal) | Small mass flow rate for regularization of zero flow [kg/s] |
| Diagnostics | |||
| Boolean | show_T | false | = true, if actual temperature at port is computed |
Connectors
| Type | Name | Description |
|---|---|---|
| FluidPort_a | port_a | Fluid connector a (positive design flow direction is from port_a to port_b) |
| FluidPort_b | port_b | Fluid connector b (positive design flow direction is from port_a to port_b) |
| replaceable model BorefieldType | Wall heat transfer | |
| input RealInput | yValIso_actual[2] | Isolation valves return position (fractional) |
| input RealInput | u | Control signal from supervisory |
| output RealOutput | PPum | Pump power [W] |
Modelica definition
model Borefield
"Base subsystem with geothermal borefield"
extends Buildings.Obsolete.BaseClasses.ObsoleteModel;
extends Buildings.Fluid.Interfaces.PartialTwoPortInterface(
final m_flow_nominal=datBorFie.conDat.mBorFie_flow_nominal);
replaceable model BorefieldType=Buildings.Fluid.Geothermal.Borefields.OneUTube
constrainedby Buildings.Fluid.Geothermal.Borefields.BaseClasses.PartialBorefield(
redeclare package Medium=Medium,
allowFlowReversal=allowFlowReversal,
borFieDat=datBorFie,
energyDynamics=Modelica.Fluid.Types.Dynamics.FixedInitial)
"Wall heat transfer";
replaceable parameter Buildings.Fluid.Geothermal.Borefields.Data.Borefield.Example
datBorFie(
conDat=Buildings.Fluid.Geothermal.Borefields.Data.Configuration.Example())
constrainedby Buildings.Fluid.Geothermal.Borefields.Data.Borefield.Template(
conDat(
dp_nominal=0))
"Borefield parameters";
parameter Modelica.Units.SI.Pressure dp_nominal(displayUnit="Pa")
"Pressure losses for the entire borefield (control valve excluded)";
parameter Modelica.Units.SI.Pressure dpValBorFie_nominal=dp_nominal/2
"Nominal pressure drop of control valve";
parameter Modelica.Units.SI.Temperature TBorWatEntMax(displayUnit="degC")
"Maximum value of borefield water entering temperature";
parameter Real spePumBorMin=0.1
"Borefield pump minimum speed";
// IO VARIABLES
Buildings.Controls.OBC.CDL.Interfaces.RealInput yValIso_actual[2]
"Isolation valves return position (fractional)";
Buildings.Controls.OBC.CDL.Interfaces.RealInput u
"Control signal from supervisory";
// COMPONENTS
Buildings.Fluid.Actuators.Valves.ThreeWayEqualPercentageLinear val(
redeclare final package Medium = Medium,
energyDynamics=Modelica.Fluid.Types.Dynamics.FixedInitial,
from_dp=false,
use_strokeTime=false,
final m_flow_nominal=m_flow_nominal,
final dpValve_nominal=dpValBorFie_nominal,
final dpFixed_nominal=fill(dp_nominal, 2))
"Mixing valve controlling entering temperature";
Buildings.DHC.ETS.BaseClasses.Pump_m_flow pum(
redeclare final package Medium=Medium,
final m_flow_nominal=m_flow_nominal,
final dp_nominal=dpValBorFie_nominal+dp_nominal)
"Pump with prescribed mass flow rate";
Buildings.Fluid.Sensors.TemperatureTwoPort senTEnt(
final tau=
if allowFlowReversal then
1
else
0,
redeclare final package Medium=Medium,
final allowFlowReversal=allowFlowReversal,
final m_flow_nominal=m_flow_nominal)
"Entering temperature";
BorefieldType borFie
"Geothermal borefield";
Buildings.DHC.ETS.BaseClasses.Junction spl(
redeclare final package Medium=Medium,
final m_flow_nominal=m_flow_nominal .* {1,-1,-1})
"Flow splitter";
Buildings.Fluid.Sensors.TemperatureTwoPort senTLvg(
redeclare final package Medium=Medium,
final allowFlowReversal=allowFlowReversal,
final m_flow_nominal=m_flow_nominal)
"Leaving temperature";
Buildings.Obsolete.DHC.ETS.Combined.Controls.Borefield con(
final TBorWatEntMax=TBorWatEntMax,
final spePumBorMin=spePumBorMin)
"Controller";
Buildings.Controls.OBC.CDL.Interfaces.RealOutput PPum(
final unit="W")
"Pump power";
Buildings.Controls.OBC.CDL.Reals.MultiplyByParameter gai1(final k=
m_flow_nominal) "Scale to nominal mass flow rate";
initial equation
assert(
abs(
datBorFie.conDat.dp_nominal) < Modelica.Constants.eps,
"In "+getInstanceName()+": dp_nominal in the parameter record should be set to zero as the nominal
pressure drop is lumped in the valve model. Use the exposed parameter
dp_nominal instead.",
level=AssertionLevel.warning);
equation
connect(pum.port_b,senTEnt.port_a);
connect(senTEnt.port_b,borFie.port_a);
connect(port_b,spl.port_2);
connect(spl.port_1,senTLvg.port_b);
connect(borFie.port_b,senTLvg.port_a);
connect(spl.port_3,val.port_3);
connect(u,con.u);
connect(yValIso_actual,con.yValIso_actual);
connect(con.yValMix,val.y);
connect(port_a,val.port_1);
connect(val.port_2,pum.port_a);
connect(senTEnt.T,con.TBorWatEnt);
connect(pum.P,PPum);
connect(con.yPum,gai1.u);
connect(gai1.y,pum.m_flow_in);
end Borefield;
Buildings.Obsolete.DHC.ETS.Combined.Subsystems.Chiller
Base subsystem with heat recovery chiller
Information
This is a model for a chiller system with constant speed evaporator and condenser pumps, and mixing valves modulated to maintain a minimum condenser inlet temperature (resp. maximum evaporator inlet temperature).
The system is controlled based on the logic described in Buildings.Obsolete.DHC.ETS.Combined.Controls.Chiller. The pump flow rate is considered proportional to the pump speed under the assumption of a constant flow resistance for both the condenser and the evaporator loops. This assumption is justified by the connection of the loops to the buffer tanks, and the additional assumption that the bypass branch of the mixing valves is balanced with the direct branch.
Extends from Buildings.Obsolete.BaseClasses.ObsoleteModel (Icon for classes that are obsolete and will be removed in later versions).
Parameters
| Type | Name | Default | Description |
|---|---|---|---|
| replaceable package Medium | Modelica.Media.Interfaces.Pa... | Medium model | |
| Generic | dat | redeclare parameter Building... | Chiller performance data |
| Nominal condition | |||
| PressureDifference | dpCon_nominal | Nominal pressure drop accross condenser [Pa] | |
| PressureDifference | dpEva_nominal | Nominal pressure drop accross evaporator [Pa] | |
| Pressure | dpValCon_nominal | dpCon_nominal/2 | Nominal pressure drop accross control valve on condenser side [Pa] |
| Pressure | dpValEva_nominal | dpEva_nominal/2 | Nominal pressure drop accross control valve on evaporator side [Pa] |
| Controls | |||
| Temperature | TConWatEntMin | dat.TConEntMin | Minimum value of condenser water entering temperature [K] |
| Temperature | TEvaWatEntMax | dat.TEvaLvgMax - dat.QEva_fl... | Maximum value of evaporator water entering temperature [K] |
| Assumptions | |||
| Boolean | allowFlowReversal | false | = true to allow flow reversal, false restricts to design direction (port_a -> port_b) |
Connectors
| Type | Name | Description |
|---|---|---|
| replaceable package Medium | Medium model | |
| input BooleanInput | uHea | Heating enable signal |
| input BooleanInput | uCoo | Cooling enable signal |
| input RealInput | TChiWatSupSet | Chilled water supply temperature set point (may be reset down) [K] |
| FluidPort_a | port_aChiWat | Fluid port for chilled water return |
| FluidPort_b | port_bChiWat | Fluid port for chilled water supply |
| FluidPort_a | port_aHeaWat | Fluid port for heating water return |
| FluidPort_b | port_bHeaWat | Fluid port for heating water supply |
| output RealOutput | PChi | Chiller power [W] |
| output RealOutput | PPum | Pump power [W] |
Modelica definition
model Chiller "Base subsystem with heat recovery chiller"
extends Buildings.Obsolete.BaseClasses.ObsoleteModel;
replaceable package Medium=Modelica.Media.Interfaces.PartialMedium
"Medium model";
parameter Boolean allowFlowReversal=false
"= true to allow flow reversal, false restricts to design direction (port_a -> port_b)";
replaceable parameter Buildings.Fluid.Chillers.Data.ElectricEIR.Generic dat
"Chiller performance data";
parameter Modelica.Units.SI.PressureDifference dpCon_nominal(displayUnit="Pa")
"Nominal pressure drop accross condenser";
parameter Modelica.Units.SI.PressureDifference dpEva_nominal(displayUnit="Pa")
"Nominal pressure drop accross evaporator";
parameter Modelica.Units.SI.Pressure dpValCon_nominal=dpCon_nominal/2
"Nominal pressure drop accross control valve on condenser side";
parameter Modelica.Units.SI.Pressure dpValEva_nominal=dpEva_nominal/2
"Nominal pressure drop accross control valve on evaporator side";
parameter Modelica.Units.SI.Temperature TConWatEntMin(displayUnit="degC")=
dat.TConEntMin "Minimum value of condenser water entering temperature";
parameter Modelica.Units.SI.Temperature TEvaWatEntMax(displayUnit="degC")=
dat.TEvaLvgMax - dat.QEva_flow_nominal/cp_default/dat.mEva_flow_nominal
"Maximum value of evaporator water entering temperature";
// IO CONNECTORS
Buildings.Controls.OBC.CDL.Interfaces.BooleanInput uHea
"Heating enable signal";
Buildings.Controls.OBC.CDL.Interfaces.BooleanInput uCoo
"Cooling enable signal";
Buildings.Controls.OBC.CDL.Interfaces.RealInput TChiWatSupSet(
final unit="K",
displayUnit="degC")
"Chilled water supply temperature set point (may be reset down)";
Modelica.Fluid.Interfaces.FluidPort_a port_aChiWat(
redeclare final package Medium=Medium,
m_flow(
min=
if allowFlowReversal then
-Modelica.Constants.inf
else
0),
h_outflow(
start=Medium.h_default,
nominal=Medium.h_default))
"Fluid port for chilled water return";
Modelica.Fluid.Interfaces.FluidPort_b port_bChiWat(
redeclare final package Medium=Medium,
m_flow(
max=
if allowFlowReversal then
+Modelica.Constants.inf
else
0),
h_outflow(
start=Medium.h_default,
nominal=Medium.h_default))
"Fluid port for chilled water supply";
Modelica.Fluid.Interfaces.FluidPort_a port_aHeaWat(
redeclare final package Medium=Medium,
m_flow(
min=
if allowFlowReversal then
-Modelica.Constants.inf
else
0),
h_outflow(
start=Medium.h_default,
nominal=Medium.h_default))
"Fluid port for heating water return";
Modelica.Fluid.Interfaces.FluidPort_b port_bHeaWat(
redeclare final package Medium=Medium,
m_flow(
max=
if allowFlowReversal then
+Modelica.Constants.inf
else
0),
h_outflow(
start=Medium.h_default,
nominal=Medium.h_default))
"Fluid port for heating water supply";
Buildings.Controls.OBC.CDL.Interfaces.RealOutput PChi(
final unit="W")
"Chiller power";
Buildings.Controls.OBC.CDL.Interfaces.RealOutput PPum(
final unit="W")
"Pump power";
// COMPONENTS
Buildings.Fluid.Chillers.ElectricEIR chi(
redeclare final package Medium1=Medium,
redeclare final package Medium2=Medium,
final allowFlowReversal1=allowFlowReversal,
final allowFlowReversal2=allowFlowReversal,
final dp1_nominal=0,
final dp2_nominal=0,
energyDynamics=Modelica.Fluid.Types.Dynamics.FixedInitial,
final per=dat)
"Water cooled chiller (ports indexed 1 are on condenser side)";
Buildings.DHC.ETS.BaseClasses.Pump_m_flow pumCon(
redeclare final package Medium=Medium,
final allowFlowReversal=allowFlowReversal,
final m_flow_nominal=dat.mCon_flow_nominal,
final dp_nominal=dpCon_nominal+dpValCon_nominal)
"Condenser pump";
Buildings.DHC.ETS.BaseClasses.Pump_m_flow pumEva(
redeclare final package Medium=Medium,
final allowFlowReversal=allowFlowReversal,
final m_flow_nominal=dat.mEva_flow_nominal,
final dp_nominal=dpEva_nominal+dpValEva_nominal)
"Evaporator pump";
Buildings.Obsolete.DHC.ETS.Combined.Controls.Chiller con(
final TConWatEntMin=TConWatEntMin,
final TEvaWatEntMax=TEvaWatEntMax)
"Controller";
Buildings.Fluid.Sensors.TemperatureTwoPort senTConLvg(
redeclare final package Medium=Medium,
final allowFlowReversal=allowFlowReversal,
final m_flow_nominal=dat.mCon_flow_nominal)
"Condenser water leaving temperature";
Buildings.Fluid.Sensors.TemperatureTwoPort senTConEnt(
redeclare final package Medium=Medium,
final allowFlowReversal=allowFlowReversal,
final m_flow_nominal=dat.mCon_flow_nominal)
"Condenser water entering temperature";
Buildings.Fluid.Sensors.TemperatureTwoPort senTEvaEnt(
redeclare final package Medium=Medium,
final allowFlowReversal=allowFlowReversal,
final m_flow_nominal=dat.mEva_flow_nominal)
"Evaporator water entering temperature";
Buildings.Fluid.Sensors.TemperatureTwoPort senTEvaLvg(
redeclare final package Medium=Medium,
final allowFlowReversal=allowFlowReversal,
final m_flow_nominal=dat.mEva_flow_nominal)
"Evaporator water leaving temperature";
Buildings.DHC.ETS.BaseClasses.Junction splEva(
redeclare final package Medium=Medium,
final m_flow_nominal=dat.mEva_flow_nominal .* {1,-1,-1})
"Flow splitter for the evaporator water circuit";
Buildings.DHC.ETS.BaseClasses.Junction splConMix(
redeclare final package Medium=Medium,
final m_flow_nominal=dat.mCon_flow_nominal .* {1,-1,-1})
"Flow splitter";
Buildings.Fluid.Actuators.Valves.ThreeWayEqualPercentageLinear valEva(
redeclare final package Medium = Medium,
energyDynamics=Modelica.Fluid.Types.Dynamics.FixedInitial,
from_dp=false,
use_strokeTime=false,
final m_flow_nominal=dat.mEva_flow_nominal,
final dpValve_nominal=dpValEva_nominal,
final dpFixed_nominal=fill(dpEva_nominal, 2))
"Control valve for maximum evaporator water entering temperature";
Buildings.Fluid.Actuators.Valves.ThreeWayEqualPercentageLinear valCon(
redeclare final package Medium = Medium,
energyDynamics=Modelica.Fluid.Types.Dynamics.FixedInitial,
from_dp=false,
use_strokeTime=false,
final m_flow_nominal=dat.mCon_flow_nominal,
final dpValve_nominal=dpValCon_nominal,
final dpFixed_nominal=fill(dpCon_nominal, 2))
"Control valve for minimum condenser water entering temperature";
Buildings.Controls.OBC.CDL.Conversions.BooleanToReal booToRea
"Constant speed primary pumps control signal";
Buildings.Controls.OBC.CDL.Reals.Add add2;
Buildings.Controls.OBC.CDL.Reals.MultiplyByParameter gai1(final k=dat.mCon_flow_nominal)
"Scale to nominal mass flow rate";
Buildings.Controls.OBC.CDL.Reals.MultiplyByParameter gai2(final k=dat.mEva_flow_nominal)
"Scale to nominal mass flow rate";
protected
final parameter Medium.ThermodynamicState sta_default=Medium.setState_pTX(
T=Medium.T_default,
p=Medium.p_default,
X=Medium.X_default[1:Medium.nXi])
"Medium state at default properties";
final parameter Modelica.Units.SI.SpecificHeatCapacity cp_default=
Medium.specificHeatCapacityCp(sta_default)
"Specific heat capacity of the fluid";
equation
connect(splConMix.port_3,valCon.port_3);
connect(valCon.port_2,pumCon.port_a);
connect(pumEva.port_b,splEva.port_1);
connect(splEva.port_3,valEva.port_3);
connect(con.yValEva,valEva.y);
connect(con.yValCon,valCon.y);
connect(con.yChi,chi.on);
connect(uHea,con.uHea);
connect(uCoo,con.uCoo);
connect(senTConEnt.T,con.TConWatEnt);
connect(senTEvaEnt.T,con.TEvaWatEnt);
connect(splConMix.port_2,port_bHeaWat);
connect(splEva.port_2,port_bChiWat);
connect(port_aHeaWat,valCon.port_1);
connect(port_aChiWat,valEva.port_1);
connect(valEva.port_2,senTEvaEnt.port_a);
connect(senTEvaLvg.port_b,pumEva.port_a);
connect(senTEvaLvg.port_a,chi.port_b2);
connect(senTEvaEnt.port_b,chi.port_a2);
connect(chi.port_b1,senTConLvg.port_a);
connect(senTConLvg.port_b,splConMix.port_1);
connect(pumCon.port_b,senTConEnt.port_a);
connect(senTConEnt.port_b,chi.port_a1);
connect(chi.P,PChi);
connect(add2.y,PPum);
connect(pumEva.P,add2.u2);
connect(pumCon.P,add2.u1);
connect(con.yChi,booToRea.u);
connect(booToRea.y,gai2.u);
connect(gai2.y,pumEva.m_flow_in);
connect(gai1.y,pumCon.m_flow_in);
connect(booToRea.y,gai1.u);
connect(TChiWatSupSet,chi.TSet);
end Chiller;
Buildings.Obsolete.DHC.ETS.Combined.Subsystems.HeatExchanger
Base subsystem with district heat exchanger
Information
This is a model for a district heat exchanger system with a variable speed pump on the secondary side, and a variable speed pump (in case of a passive network) or a two-way modulating valve (in case of an active network) on the primary side.
The system is controlled based on the logic described in Buildings.Obsolete.DHC.ETS.Combined.Controls.HeatExchanger. The pump flow rate is considered proportional to the pump speed under the assumption of a constant flow resistance in both the primary and the secondary loops.
Extends from Buildings.Obsolete.BaseClasses.ObsoleteModel (Icon for classes that are obsolete and will be removed in later versions), Buildings.Fluid.Interfaces.PartialFourPortInterface (Partial model with four ports and declaration of quantities that are used by many models).
Parameters
| Type | Name | Default | Description |
|---|---|---|---|
| replaceable package Medium1 | PartialMedium | Medium 1 in the component | |
| replaceable package Medium2 | PartialMedium | Medium 2 in the component | |
| ConnectionConfiguration | conCon | District connection configuration | |
| Nominal condition | |||
| MassFlowRate | m1_flow_nominal | abs(Q_flow_nominal/4200/(T_b... | Nominal mass flow rate [kg/s] |
| MassFlowRate | m2_flow_nominal | abs(Q_flow_nominal/4200/(T_b... | Nominal mass flow rate [kg/s] |
| PressureDifference | dp1Hex_nominal | Nominal pressure drop across heat exchanger on district side [Pa] | |
| PressureDifference | dp2Hex_nominal | Nominal pressure drop across heat exchanger on building side [Pa] | |
| PressureDifference | dpVal1_nominal | dp1Hex_nominal/2 | Nominal pressure drop of primary control valve [Pa] |
| PressureDifference | dpVal2_nominal | dp2Hex_nominal/2 | Nominal pressure drop of secondary control valve [Pa] |
| HeatFlowRate | Q_flow_nominal | Nominal heat flow rate (from district to building) [W] | |
| Temperature | T_a1_nominal | Nominal water inlet temperature on district side [K] | |
| Temperature | T_b1_nominal | Nominal water outlet temperature on district side [K] | |
| Temperature | T_a2_nominal | Nominal water inlet temperature on building side [K] | |
| Temperature | T_b2_nominal | Nominal water outlet temperature on building side [K] | |
| Controls | |||
| Real | spePum1Min | 0.1 | Heat exchanger primary pump minimum speed (fractional) [1] |
| Real | spePum2Min | 0.1 | Heat exchanger secondary pump minimum speed (fractional) [1] |
| Assumptions | |||
| Boolean | allowFlowReversal1 | true | = false to simplify equations, assuming, but not enforcing, no flow reversal for medium 1 |
| Boolean | allowFlowReversal2 | true | = false to simplify equations, assuming, but not enforcing, no flow reversal for medium 2 |
| Advanced | |||
| MassFlowRate | m1_flow_small | 1E-4*abs(m1_flow_nominal) | Small mass flow rate for regularization of zero flow [kg/s] |
| MassFlowRate | m2_flow_small | 1E-4*abs(m2_flow_nominal) | Small mass flow rate for regularization of zero flow [kg/s] |
| Diagnostics | |||
| Boolean | show_T | false | = true, if actual temperature at port is computed |
Connectors
| Type | Name | Description |
|---|---|---|
| FluidPort_a | port_a1 | Fluid connector a1 (positive design flow direction is from port_a1 to port_b1) |
| FluidPort_b | port_b1 | Fluid connector b1 (positive design flow direction is from port_a1 to port_b1) |
| FluidPort_a | port_a2 | Fluid connector a2 (positive design flow direction is from port_a2 to port_b2) |
| FluidPort_b | port_b2 | Fluid connector b2 (positive design flow direction is from port_a2 to port_b2) |
| input RealInput | yValIso_actual[2] | Isolation valves return position (index 1 for condenser) |
| input RealInput | u | Control signal for secondary side (from supervisory) |
| output RealOutput | PPum | Power drawn by pump motors [W] |
Modelica definition
model HeatExchanger "Base subsystem with district heat exchanger"
extends Buildings.Obsolete.BaseClasses.ObsoleteModel;
extends Buildings.Fluid.Interfaces.PartialFourPortInterface(
final m1_flow_nominal=abs(Q_flow_nominal/4200/(T_b1_nominal - T_a1_nominal)),
final m2_flow_nominal=abs(Q_flow_nominal/4200/(T_b2_nominal - T_a2_nominal)));
parameter Buildings.DHC.ETS.Types.ConnectionConfiguration conCon
"District connection configuration";
parameter Modelica.Units.SI.PressureDifference dp1Hex_nominal(displayUnit=
"Pa") "Nominal pressure drop across heat exchanger on district side";
parameter Modelica.Units.SI.PressureDifference dp2Hex_nominal(displayUnit=
"Pa") "Nominal pressure drop across heat exchanger on building side";
parameter Modelica.Units.SI.PressureDifference dpVal1_nominal(displayUnit=
"Pa") = dp1Hex_nominal/2
"Nominal pressure drop of primary control valve";
parameter Modelica.Units.SI.PressureDifference dpVal2_nominal(displayUnit=
"Pa") = dp2Hex_nominal/2
"Nominal pressure drop of secondary control valve";
parameter Modelica.Units.SI.HeatFlowRate Q_flow_nominal
"Nominal heat flow rate (from district to building)";
parameter Modelica.Units.SI.Temperature T_a1_nominal
"Nominal water inlet temperature on district side";
parameter Modelica.Units.SI.Temperature T_b1_nominal
"Nominal water outlet temperature on district side";
parameter Modelica.Units.SI.Temperature T_a2_nominal
"Nominal water inlet temperature on building side";
parameter Modelica.Units.SI.Temperature T_b2_nominal
"Nominal water outlet temperature on building side";
parameter Real spePum1Min(unit="1")=0.1
"Heat exchanger primary pump minimum speed (fractional)";
parameter Real spePum2Min(unit="1")=0.1
"Heat exchanger secondary pump minimum speed (fractional)";
// IO CONNECTORS
Buildings.Controls.OBC.CDL.Interfaces.RealInput yValIso_actual[2]
"Isolation valves return position (index 1 for condenser)";
Buildings.Controls.OBC.CDL.Interfaces.RealInput u
"Control signal for secondary side (from supervisory)";
Buildings.Controls.OBC.CDL.Interfaces.RealOutput PPum(
final unit="W")
"Power drawn by pump motors";
// COMPONENTS
Buildings.Obsolete.DHC.ETS.Combined.Controls.HeatExchanger con(
final conCon=conCon,
final spePum1Min=spePum1Min,
final spePum2Min=spePum2Min)
"District heat exchanger loop controller";
Buildings.Fluid.HeatExchangers.PlateHeatExchangerEffectivenessNTU hex(
redeclare final package Medium1 = Medium1,
redeclare final package Medium2 = Medium2,
show_T=true,
final use_Q_flow_nominal=true,
configuration=Buildings.Fluid.Types.HeatExchangerConfiguration.CounterFlow,
final allowFlowReversal1=allowFlowReversal1,
final allowFlowReversal2=allowFlowReversal2,
final dp1_nominal=if have_val1 then 0 else dp1Hex_nominal,
final dp2_nominal=0,
final m1_flow_nominal=m1_flow_nominal,
final m2_flow_nominal=m2_flow_nominal,
final Q_flow_nominal=Q_flow_nominal,
final T_a1_nominal=T_a1_nominal,
final T_a2_nominal=T_a2_nominal)
"Heat exchanger";
Buildings.DHC.ETS.BaseClasses.Pump_m_flow pum1(
redeclare final package Medium = Medium1,
final m_flow_nominal=m1_flow_nominal,
final dp_nominal=dp1Hex_nominal,
final allowFlowReversal=allowFlowReversal1) if not have_val1
"District heat exchanger primary pump";
Buildings.DHC.ETS.BaseClasses.Pump_m_flow pum2(
redeclare final package Medium = Medium2,
final m_flow_nominal=m2_flow_nominal,
final dp_nominal=dp2Hex_nominal + dpVal2_nominal,
final allowFlowReversal=allowFlowReversal2) "Secondary pump";
Buildings.Fluid.Sensors.TemperatureTwoPort senT2WatEnt(
redeclare final package Medium = Medium2,
final m_flow_nominal=m2_flow_nominal,
final allowFlowReversal=allowFlowReversal2)
"Heat exchanger secondary water entering temperature";
Buildings.Fluid.Sensors.TemperatureTwoPort senT2WatLvg(
redeclare final package Medium = Medium2,
final m_flow_nominal=m2_flow_nominal,
final allowFlowReversal=allowFlowReversal2)
"Heat exchanger secondary water leaving temperature";
Buildings.Controls.OBC.CDL.Reals.MultiplyByParameter gai2(final k=
m2_flow_nominal) "Scale to nominal mass flow rate";
Buildings.Fluid.Actuators.Valves.TwoWayPressureIndependent val1(
redeclare final package Medium = Medium1,
final m_flow_nominal=m1_flow_nominal,
from_dp=true,
final dpValve_nominal=dpVal1_nominal,
use_strokeTime=false,
final dpFixed_nominal=dp1Hex_nominal) if have_val1
"Heat exchanger primary control valve";
Buildings.Controls.OBC.CDL.Reals.MultiplyByParameter gai1(final k=
m1_flow_nominal) if not have_val1 "Scale to nominal mass flow rate";
Buildings.Controls.OBC.CDL.Reals.MultiSum totPPum(
final nin=
if have_val1 then
1
else
2)
"Total pump power";
Buildings.Fluid.Actuators.Valves.ThreeWayEqualPercentageLinear val2(
redeclare final package Medium = Medium2,
energyDynamics=Modelica.Fluid.Types.Dynamics.FixedInitial,
from_dp=false,
use_strokeTime=false,
final m_flow_nominal=m2_flow_nominal,
final dpValve_nominal=dpVal2_nominal,
final dpFixed_nominal=fill(dp2Hex_nominal, 2)) "Control valve";
Buildings.DHC.ETS.BaseClasses.Junction spl(redeclare final package Medium =
Medium2, final m_flow_nominal=m2_flow_nominal .* {1,-1,-1})
"Flow splitter";
protected
parameter Boolean have_val1=
conCon ==Buildings.DHC.ETS.Types.ConnectionConfiguration.TwoWayValve
"True in case of control valve on district side, false in case of a pump";
equation
if have_val1 then
connect(port_a1, hex.port_a1);
else
connect(hex.port_b1, port_b1);
end if;
connect(gai2.y,pum2.m_flow_in);
connect(port_a1,pum1.port_a);
connect(val1.port_b,port_b1);
connect(pum2.port_b,senT2WatEnt.port_a);
connect(senT2WatEnt.port_b,hex.port_a2);
connect(con.y1, val1.y);
connect(con.y1, gai1.u);
connect(gai1.y,pum1.m_flow_in);
connect(pum1.P,totPPum.u[2]);
connect(pum2.P,totPPum.u[1]);
connect(totPPum.y,PPum);
connect(yValIso_actual,con.yValIso);
connect(con.yPum2,gai2.u);
connect(u,con.u);
connect(hex.port_b2,senT2WatLvg.port_a);
connect(val2.port_2,pum2.port_a);
connect(port_a2,val2.port_1);
connect(spl.port_1,senT2WatLvg.port_b);
connect(spl.port_2,port_b2);
connect(spl.port_3,val2.port_3);
connect(con.yVal2,val2.y);
connect(hex.port_b1, val1.port_a);
connect(pum1.port_b, hex.port_a1);
end HeatExchanger;
Buildings.Obsolete.DHC.ETS.Combined.Subsystems.Borefield.BorefieldType
Wall heat transfer
Parameters
| Type | Name | Default | Description |
|---|---|---|---|
| replaceable package Medium | PartialMedium | Medium in the component | |
| Time | tLoaAgg | 300 | Time resolution of load aggregation [s] |
| Integer | nCel | 5 | Number of cells per aggregation level |
| Integer | nSeg | 10 | Number of segments to use in vertical discretization of the boreholes |
| Template | borFieDat | Borefield data | |
| Assumptions | |||
| Boolean | allowFlowReversal | true | = false to simplify equations, assuming, but not enforcing, no flow reversal |
| Advanced | |||
| MassFlowRate | m_flow_small | 1E-4*abs(m_flow_nominal) | Small mass flow rate for regularization of zero flow [kg/s] |
| Diagnostics | |||
| Boolean | show_T | false | = true, if actual temperature at port is computed |
| g-function | |||
| Boolean | forceGFunCalc | false | Set to true to force the thermal response to be calculated at the start instead of checking whether this has been pre-computed |
| Integer | nSegGFun | 12 | Number of segments to use in the calculation of the g-function |
| Integer | nClu | 5 | Number of borehole clusters to use in the calculation of the g-function |
| Flow resistance | |||
| Boolean | from_dp | false | = true, use m_flow = f(dp) else dp = f(m_flow) |
| Boolean | linearizeFlowResistance | false | = true, use linear relation between m_flow and dp for any flow rate |
| Real | deltaM | 0.1 | Fraction of nominal flow rate where flow transitions to laminar |
| Dynamics | |||
| Conservation equations | |||
| Dynamics | energyDynamics | Modelica.Fluid.Types.Dynamic... | Type of energy balance: dynamic (3 initialization options) or steady state |
| Initialization | |||
| AbsolutePressure | p_start | Medium.p_default | Start value of pressure [Pa] |
| Temperature | TFlu_start[nSeg] | TGro_start | Start value of fluid temperature [K] |
| Soil | |||
| Temperature | TExt0_start | 283.15 | Initial far field temperature [K] |
| Temperature | TExt_start[nSeg] | {if z[i] >= z0 then TExt0_st... | Temperature of the undisturbed ground [K] |
| Filling material | |||
| Temperature | TGro_start[nSeg] | TExt_start | Start value of grout temperature [K] |
| Temperature profile | |||
| Height | z0 | 10 | Depth below which the temperature gradient starts [m] |
| Real | dT_dz | 0.01 | Vertical temperature gradient of the undisturbed soil for h below z0 [K/m] |
Connectors
| Type | Name | Description |
|---|---|---|
| FluidPort_a | port_a | Fluid connector a (positive design flow direction is from port_a to port_b) |
| FluidPort_b | port_b | Fluid connector b (positive design flow direction is from port_a to port_b) |
| output RealOutput | TBorAve | Average borehole wall temperature in the borefield [K] |
Modelica definition
replaceable model BorefieldType=Buildings.Fluid.Geothermal.Borefields.OneUTube
constrainedby Buildings.Fluid.Geothermal.Borefields.BaseClasses.PartialBorefield(
redeclare package Medium=Medium,
allowFlowReversal=allowFlowReversal,
borFieDat=datBorFie,
energyDynamics=Modelica.Fluid.Types.Dynamics.FixedInitial)
"Wall heat transfer";
