Buildings.DHC.Examples.Combined.ETSHeatRecoveryHeatPump_BuildingTimeSeries.BaseClasses
Package with base classes for Buildings.DHC.Examples.Combined.ETSHeatRecoveryHeatPump_BuildingTimeSeries
Information
This package contains base classes that are used to construct the models in Buildings.DHC.Examples.Combined.ETSHeatRecoveryHeatPump_BuildingTimeSeries.
Extends from Modelica.Icons.BasesPackage (Icon for packages containing base classes).
Package Content
| Name | Description |
|---|---|
 BuildingETS
|
Load connected to the network via ETS with or without DHW integration |
 BuildingTimeSeries
|
Building load with time series and control valve for supply water temperature to the coils |
Buildings.DHC.Examples.Combined.ETSHeatRecoveryHeatPump_BuildingTimeSeries.BaseClasses.BuildingETS
Load connected to the network via ETS with or without DHW integration
Information
Model that connects a building thermal and cooling load, specified by time series, with an energy transfer station, and exposes the fluid connections of the energy transfer station for connecting it to district energy service lines.
The model extends from Buildings.DHC.Loads.BaseClasses.PartialBuildingWithPartialETS, which connects the building and the load, and exposes the fluid connection for connecting it to the district service line. The building load is modeled by reading time series, and drawing as much heating or cooling water as determined by its control. This is implemented through Buildings.DHC.Examples.Combined.ETSHeatRecoveryHeatPump_BuildingTimeSeries.BaseClasses.BuildingTimeSeries. The energy transfer station uses a heat recovery heat pump, and can optionally have domestic hot water preparation. This is implemented in Buildings.DHC.ETS.Combined.HeatRecoveryHeatPump.
See the respective models for a detailed description.
Extends from Buildings.DHC.Loads.BaseClasses.PartialBuildingWithPartialETS (Partial model of a building with an energy transfer station).
Parameters
| Type | Name | Default | Description |
|---|---|---|---|
| replaceable package MediumSer | Water | Service side medium | |
| replaceable package MediumSerHea_a | Water | Service side medium at heating inlet | |
| replaceable package MediumBui | Water | Building side medium | |
| Real | facTerUniSizHea | Factor to increase design capacity of space terminal units for heating [1] | |
| String | filNam | File name for the load profile | |
| HVAC | datBuiSet | Building set points | |
| WAMAK_220kW | datHeaPum | datHeaPum(PLRMin=0.2/3 "20%,... | Heat recovery heat pump parameters |
| GenericDomesticHotWaterWithHeatExchanger | datDhw | datDhw(VTan=datHeaPum.mCon_f... | Performance data of the domestic hot water component |
| Table | THeaWatSupSet | THeaWatSupSet(final table=da... | Heating water supply temperature set point |
| Table | TChiWatSupSet | TChiWatSupSet(final table=da... | Chilled water supply temperature set point |
| Constant | THotWatSupSet | THotWatSupSet(final k(final ... | Domestic hot water supply temperature set point |
| Constant | TColWat | TColWat(final k(final unit="... | Domestic cold water temperature |
| Configuration | |||
| Integer | nPorts_heaWat | 1 | Number of heating water fluid ports |
| Integer | nPorts_chiWat | 1 | Number of chilled water fluid ports |
| Boolean | have_eleNonHva | Set to true to enable a data reader and output signal for non-HVAC electrical load | |
| Scaling | |||
| Real | facMul | 1 | Multiplier factor |
| Nominal condition | |||
| TemperatureDifference | dT_nominal | 4 | Water temperature drop/increase accross load and source-side HX (always positive) [K] |
| Temperature | TChiWatSup_nominal | datBuiSet.TChiWatSup_nominal | Chilled water supply temperature to building load [K] |
| Temperature | THeaWatSup_nominal | datBuiSet.THeaWatSup_nominal | Heating water supply temperature to building load [K] |
| Design parameter | |||
| HeatFlowRate | QCoo_flow_nominal | Buildings.DHC.Loads.BaseClas... | Design cooling heat flow rate (<=0) [W] |
| HeatFlowRate | QHea_flow_nominal | Buildings.DHC.Loads.BaseClas... | Design heating heat flow rate (>=0) [W] |
| HeatFlowRate | QHot_flow_nominal | Buildings.DHC.Loads.BaseClas... | Design heating heat flow rate (>=0) [W] |
| ETS model parameters | |||
| Temperature | THotWatSup_nominal | datBuiSet.THotWatSupFix_nomi... | Domestic hot water supply temperature to fixtures [K] |
| Assumptions | |||
| Boolean | allowFlowReversalSer | false | Set to true to allow flow reversal on service side |
| Boolean | allowFlowReversalBui | false | Set to true to allow flow reversal on building side |
Connectors
| Type | Name | Description |
|---|---|---|
| FluidPort_a | port_aSerAmb | Fluid connector for ambient water service supply line |
| FluidPort_b | port_bSerAmb | Fluid connector for ambient water service return line |
| FluidPort_a | port_aSerHea | Fluid connector for heating service supply line |
| FluidPort_b | port_bSerHea | Fluid connector for heating service return line |
| FluidPort_a | port_aSerCoo | Fluid connector for cooling service supply line |
| FluidPort_b | port_bSerCoo | Fluid connector for cooling service return line |
| Bus | weaBus | Weather data bus |
| output RealOutput | QHea_flow | Total heating heat flow rate transferred to the loads (>=0) [W] |
| output RealOutput | QCoo_flow | Total cooling heat flow rate transferred to the loads (<=0) [W] |
| output RealOutput | PHea | Power drawn by heating system [W] |
| output RealOutput | PCoo | Power drawn by cooling system [W] |
| output RealOutput | PFan | Power drawn by fan motors [W] |
| output RealOutput | PPum | Power drawn by pump motors [W] |
| output RealOutput | QFue_flow[nFue] | Fuel energy input rate [W] |
| output RealOutput | PEleNonHva | Power drawn by non-HVAC electricity load [W] |
| output RealOutput | dHHeaWat_flow | Heating water distributed energy flow rate [W] |
| output RealOutput | dHChiWat_flow | Chilled water distributed energy flow rate [W] |
| output RealOutput | dHHotWat_flow | Domestic hot water distributed energy flow rate [W] |
Modelica definition
model BuildingETS
"Load connected to the network via ETS with or without DHW integration"
extends Buildings.DHC.Loads.BaseClasses.PartialBuildingWithPartialETS(
redeclare Buildings.DHC.Examples.Combined.ETSHeatRecoveryHeatPump_BuildingTimeSeries.BaseClasses.BuildingTimeSeries
bui(
final filNam=filNam,
final T_aHeaWat_nominal=datBuiSet.THeaWatSup_nominal,
final T_bHeaWat_nominal=datBuiSet.THeaWatRet_nominal,
final T_aChiWat_nominal=datBuiSet.TChiWatSup_nominal,
final T_bChiWat_nominal=datBuiSet.TChiWatRet_nominal,
final have_hotWat=have_hotWat,
QHea_flow_nominal=facTerUniSizHea*Buildings.DHC.Loads.BaseClasses.getPeakLoad(
string="#Peak space heating load",
filNam=Modelica.Utilities.Files.loadResource(filNam))),
redeclare Buildings.DHC.ETS.Combined.HeatRecoveryHeatPump ets(
final have_hotWat=QHotWat_flow_nominal > Modelica.Constants.eps,
QChiWat_flow_nominal=QCoo_flow_nominal,
QHeaWat_flow_nominal=QHea_flow_nominal,
QHotWat_flow_nominal=QHot_flow_nominal,
dp1Hex_nominal=40E3,
dp2Hex_nominal=40E3,
QHex_flow_nominal=max(abs(QCoo_flow_nominal),QHea_flow_nominal),
T_a1Hex_nominal=283.65,
T_b1Hex_nominal=279.65,
T_a2Hex_nominal=276.65,
T_b2Hex_nominal=282.65,
QWSE_flow_nominal=QCoo_flow_nominal,
VTanHeaWat=datHeaPum.mCon_flow_nominal*datBuiSet.dTHeaWat_nominal*5*60/
1000,
VTanChiWat=datHeaPum.mEva_flow_nominal*datBuiSet.dTChiWat_nominal*5*60/
1000,
have_WSE=false,
dpCon_nominal=40E3,
dpEva_nominal=40E3,
datDhw=datDhw,
TCon_start=if have_hotWat then min(datBuiSet.THeaWatSup_nominal,
datBuiSet.THotWatSupTan_nominal) else datBuiSet.THeaWatSup_nominal,
TEva_start=datBuiSet.TChiWatSup_nominal,
datHeaPum=datHeaPum),
nPorts_heaWat=1,
nPorts_chiWat=1);
parameter Boolean have_eleNonHva
"Set to true to enable a data reader and output signal for non-HVAC electrical load";
parameter Real facTerUniSizHea(final unit="1")
"Factor to increase design capacity of space terminal units for heating";
parameter String filNam "File name for the load profile";
parameter Modelica.Units.SI.HeatFlowRate QCoo_flow_nominal(
max=-Modelica.Constants.eps)=
Buildings.DHC.Loads.BaseClasses.getPeakLoad(
string="#Peak space cooling load",
filNam=Modelica.Utilities.Files.loadResource(filNam))
"Design cooling heat flow rate (<=0)";
parameter Modelica.Units.SI.HeatFlowRate QHea_flow_nominal(
min=Modelica.Constants.eps)=
Buildings.DHC.Loads.BaseClasses.getPeakLoad(
string="#Peak space heating load",
filNam=Modelica.Utilities.Files.loadResource(filNam))
"Design heating heat flow rate (>=0)";
parameter Buildings.DHC.Examples.Combined.ETSHeatRecoveryHeatPump_BuildingTimeSeries.Data.HVAC
datBuiSet
"Building set points";
parameter Buildings.DHC.ETS.Combined.Data.WAMAK_220kW datHeaPum(
PLRMin=0.2/3 "20%, and assume 3 chillers in parallel",
QHeaDes_flow_nominal=max(QHea_flow_nominal, abs(QCoo_flow_nominal)*1.2),
QCooDes_flow_nominal=QCoo_flow_nominal,
final dTCon_nominal=datBuiSet.dTHeaWat_nominal,
final dTEva_nominal=datBuiSet.dTChiWat_nominal,
THeaConLvg_nominal=max(datBuiSet.THeaWatSup_nominal, datBuiSet.THotWatSupTan_nominal),
THeaEvaLvg_nominal=273.15 + 3.5,
TCooConLvg_nominal=273.15 + 31,
TCooEvaLvg_nominal=datBuiSet.TChiWatSup_nominal)
"Heat recovery heat pump parameters";
final parameter Modelica.Units.SI.Temperature TChiWatRet_nominal=
datBuiSet.TChiWatRet_nominal "Chilled water return temperature from building load";
final parameter Modelica.Units.SI.Temperature THeaWatRet_nominal=
datBuiSet.THeaWatRet_nominal "Heating water return temperature from building load";
parameter Modelica.Units.SI.TemperatureDifference dT_nominal(min=0) = 4
"Water temperature drop/increase accross load and source-side HX (always positive)";
parameter Modelica.Units.SI.Temperature TChiWatSup_nominal =
datBuiSet.TChiWatSup_nominal "Chilled water supply temperature to building load";
parameter Modelica.Units.SI.Temperature THeaWatSup_nominal =
datBuiSet.THeaWatSup_nominal "Heating water supply temperature to building load";
parameter Modelica.Units.SI.Temperature THotWatSup_nominal =
datBuiSet.THotWatSupFix_nominal "Domestic hot water supply temperature to fixtures";
parameter Buildings.DHC.Loads.HotWater.Data.GenericDomesticHotWaterWithHeatExchanger
datDhw(
VTan=datHeaPum.mCon_flow_nominal*datBuiSet.dTHeaWat_nominal*5*60/1000,
mDom_flow_nominal=datDhw.QHex_flow_nominal/4200/(datDhw.TDom_nominal-datDhw.TCol_nominal),
QHex_flow_nominal=if have_hotWat then QHotWat_flow_nominal else
QHeaWat_flow_nominal,
TDom_nominal=datBuiSet.THotWatSupTan_nominal)
"Performance data of the domestic hot water component";
parameter Modelica.Units.SI.HeatFlowRate QHot_flow_nominal(
min=0)=Buildings.DHC.Loads.BaseClasses.getPeakLoad(
string="#Peak water heating load",
filNam=Modelica.Utilities.Files.loadResource(filNam))
"Design heating heat flow rate (>=0)";
// Replaceable sources for set points and for fresh water supply
replaceable Buildings.Controls.SetPoints.Table THeaWatSupSet(
final table=datBuiSet.tabHeaWatRes,
final offset=0,
final constantExtrapolation=true)
constrainedby Modelica.Blocks.Interfaces.SISO(
y(final unit="K", displayUnit="degC"))
"Heating water supply temperature set point";
replaceable Buildings.Controls.SetPoints.Table TChiWatSupSet(
final table=datBuiSet.tabChiWatRes,
final offset=0,
final constantExtrapolation=true)
constrainedby Modelica.Blocks.Interfaces.SISO(
y(final unit="K", displayUnit="degC"))
"Chilled water supply temperature set point";
replaceable Buildings.Controls.OBC.CDL.Reals.Sources.Constant THotWatSupSet(
final k(final unit="K", displayUnit="degC")=datBuiSet.THotWatSupFix_nominal)
if have_hotWat
constrainedby Modelica.Blocks.Interfaces.SO(y(final unit="K", displayUnit="degC"))
"Domestic hot water supply temperature set point";
replaceable Buildings.Controls.OBC.CDL.Reals.Sources.Constant TColWat(
final k(final unit="K", displayUnit="degC")=288.15)
if have_hotWat
constrainedby Modelica.Blocks.Interfaces.SO(y(final unit="K", displayUnit="degC"))
"Domestic cold water temperature";
// Output connectors for main energy use
Buildings.Controls.OBC.CDL.Interfaces.RealOutput PEleNonHva(final unit="W")
if have_eleNonHva
"Power drawn by non-HVAC electricity load";
Buildings.Controls.OBC.CDL.Interfaces.RealOutput dHHeaWat_flow(final unit="W")
"Heating water distributed energy flow rate";
Buildings.Controls.OBC.CDL.Interfaces.RealOutput dHChiWat_flow(final unit="W")
"Chilled water distributed energy flow rate";
Buildings.Controls.OBC.CDL.Interfaces.RealOutput dHHotWat_flow(final unit="W")
if have_hotWat
"Domestic hot water distributed energy flow rate";
Modelica.Blocks.Sources.CombiTimeTable loaEleNonHva(
final tableOnFile=true,
tableName="tab1",
final fileName=Modelica.Utilities.Files.loadResource(filNam),
extrapolation=bui.loa.extrapolation,
y(each unit="W"),
timeScale=bui.loa.timeScale,
offset={0},
columns={5},
smoothness=bui.loa.smoothness) if have_eleNonHva
"Reader for non-HVAC electricity load";
Buildings.Controls.OBC.CDL.Reals.MultiplyByParameter mulPEleNonHva(
u(final unit="W"),
final k=facMul) if have_eleNonHva "Scaling";
equation
connect(ets.QReqHotWat_flow, bui.QReqHotWat_flow);
connect(ets.THotWatSupSet, THotWatSupSet.y);
connect(TColWat.y, ets.TColWat);
connect(ets.dHChiWat_flow, dHChiWat_flow);
connect(dHHeaWat_flow, ets.dHHeaWat_flow);
connect(ets.dHHotWat_flow, dHHotWat_flow);
connect(THeaWatSupSet.y, ets.THeaWatSupSet);
connect(weaBus.TDryBul, THeaWatSupSet.u);
connect(TChiWatSupSet.y, ets.TChiWatSupSet);
connect(weaBus.TDryBul, TChiWatSupSet.u);
connect(mulPEleNonHva.y, PEleNonHva);
connect(loaEleNonHva.y[1], mulPEleNonHva.u);
connect(bui.THeaSupSet, THeaWatSupSet.y);
connect(TChiWatSupSet.y, bui.TCooSupSet);
end BuildingETS;
Buildings.DHC.Examples.Combined.ETSHeatRecoveryHeatPump_BuildingTimeSeries.BaseClasses.BuildingTimeSeries
Building load with time series and control valve for supply water temperature to the coils
Information
Model of a building heating and cooling load based on time series data.
This model is identical to Buildings.DHC.Loads.BaseClasses.BuildingTimeSeries, but it adds input signals for the heating and cooling supply water temperature, and configures the above model to use a three-way control valve to mix the heating and cooling supply water to the temperature described by these two input signals.
Extends from Buildings.DHC.Loads.BaseClasses.BuildingTimeSeries (Building model with heating and/or cooling loads provided as time series).
Parameters
| Type | Name | Default | Description |
|---|---|---|---|
| replaceable package Medium2 | Air | Load side medium | |
| String | filNam | File name with thermal loads as time series | |
| Real | k | 0.1 | Gain of controller |
| Time | Ti | 10 | Time constant of integrator block [s] |
| FanCoil2PipeHeating | terUniHea | redeclare Buildings.DHC.Load... | Heating terminal unit |
| FanCoil2PipeCooling | terUniCoo | redeclare Buildings.DHC.Load... | Cooling terminal unit |
| Configuration | |||
| Boolean | have_heaWat | true | Set to true if the building has heating water system |
| Boolean | have_chiWat | true | Set to true if the building has chilled water system |
| Boolean | have_hotWat | false | Set to true if SHW load is included in the time series |
| Scaling | |||
| Real | facMul | 1 | Multiplier factor |
| Nominal condition | |||
| Temperature | T_aHeaWat_nominal | 323.15 | Heating water inlet temperature at nominal conditions [K] |
| Temperature | T_bHeaWat_nominal | T_aHeaWat_nominal - 10 | Heating water outlet temperature at nominal conditions [K] |
| Temperature | T_aChiWat_nominal | 280.15 | Chilled water inlet temperature at nominal conditions [K] |
| Temperature | T_bChiWat_nominal | T_aChiWat_nominal + 5 | Chilled water outlet temperature at nominal conditions [K] |
| HeatFlowRate | QCoo_flow_nominal | if have_chiWat then Building... | Design cooling heat flow rate (<=0) [W] |
| HeatFlowRate | QHea_flow_nominal | if have_heaWat then Building... | Design heating heat flow rate (>=0) [W] |
| MassFlowRate | mChiWat_flow_nominal | QCoo_flow_nominal/cp_default... | Chilled water mass flow rate at nominal conditions (all units) [kg/s] |
| MassFlowRate | mHeaWat_flow_nominal | QHea_flow_nominal/cp_default... | Heating water mass flow rate at nominal conditions (all units) [kg/s] |
| Assumptions | |||
| Boolean | allowFlowReversal | false | = true to allow flow reversal, false restricts to design direction (port_a -> port_b) |
| Advanced | |||
| Scaling | |||
| Real | facMulHea | QHea_flow_nominal/(QHea_flow... | Heating terminal unit multiplier factor |
| Real | facMulCoo | QCoo_flow_nominal/(QCoo_flow... | Cooling terminal unit scaling factor |
| Nominal condition | |||
| Temperature | T_aLoaHea_nominal | 293.15 | Load side inlet temperature at nominal conditions in heating mode [K] |
| Temperature | T_aLoaCoo_nominal | 298.15 | Load side inlet temperature at nominal conditions in cooling mode [K] |
| MassFraction | w_aLoaCoo_nominal | 0.01 | Load side inlet humidity ratio at nominal conditions in cooling mode [1] |
| MassFlowRate | mLoaHea_flow_nominal | 0.5 | Load side mass flow rate at nominal conditions in heating mode (single unit) [kg/s] |
| MassFlowRate | mLoaCoo_flow_nominal | mLoaHea_flow_nominal | Load side mass flow rate at nominal conditions in cooling mode (single unit) [kg/s] |
| Reference terminal unit performance | |||
| Temperature | T_aHeaWat_nominal_ref | 323.15 | Heating water inlet temperature at nominal conditions of reference terminal unit [K] |
| Temperature | T_aLoaHea_nominal_ref | 293.15 | Load side inlet temperature at nominal conditions in heating mode of reference terminal unit [K] |
| MassFlowRate | mLoaHea_flow_nominal_ref | 0.5 | Load side mass flow rate at nominal conditions in heating mode of reference terminal unit [kg/s] |
| HeatFlowRate | QHea_flow_nominal_ref | 4.5E3 | Heat flow at nominal conditions in heating mode of reference terminal unit [W] |
| Temperature | T_aChiWat_nominal_ref | 279.15 | Chilled water inlet temperature at nominal conditions of reference terminal unit [K] |
| Temperature | T_aLoaCoo_nominal_ref | 298.15 | Load side inlet temperature at nominal conditions in cooling mode of reference terminal unit [K] |
| MassFraction | w_aLoaCoo_nominal_ref | 0.01 | Load side inlet humidity ratio at nominal conditions in cooling mode of reference terminal unit [1] |
| MassFlowRate | mLoaCoo_flow_nominal_ref | 0.5 | Load side mass flow rate at nominal conditions in cooling mode of reference terminal unit [kg/s] |
| HeatFlowRate | QCoo_flow_nominal_ref | -5.8E3 | Heat flow at nominal conditions in cooling mode of reference terminal unit [W] |
Connectors
| Type | Name | Description |
|---|---|---|
| Bus | weaBus | Weather data bus |
| FluidPorts_a | ports_aHeaWat[nPorts_aHeaWat] | Heating water inlet ports |
| FluidPorts_b | ports_bHeaWat[nPorts_bHeaWat] | Heating water outlet ports |
| FluidPorts_a | ports_aChiWat[nPorts_aChiWat] | Chilled water inlet ports |
| FluidPorts_b | ports_bChiWat[nPorts_bChiWat] | Chilled water outlet ports |
| output RealOutput | QHea_flow | Total heating heat flow rate transferred to the loads (>=0) [W] |
| output RealOutput | QCoo_flow | Total cooling heat flow rate transferred to the loads (<=0) [W] |
| output RealOutput | PHea | Power drawn by decentralized heating system [W] |
| output RealOutput | PCoo | Power drawn by decentralized cooling system [W] |
| output RealOutput | PFan | Power drawn by fan motors [W] |
| output RealOutput | PPum | Power drawn by pump motors [W] |
| output RealOutput | QReqHotWat_flow | SHW load [W] |
| output RealOutput | QReqHea_flow | Heating load [W] |
| output RealOutput | QReqCoo_flow | Cooling load [W] |
| input RealInput | THeaSupSet | Supply temperature set point for heating [K] |
| input RealInput | TCooSupSet | Supply temperature set point for cooling [K] |
Modelica definition
model BuildingTimeSeries
"Building load with time series and control valve for supply water temperature to the coils"
extends Buildings.DHC.Loads.BaseClasses.BuildingTimeSeries(
disFloHea(have_val=true),
disFloCoo(have_val=true));
Modelica.Blocks.Interfaces.RealInput THeaSupSet(
final unit="K",
displayUnit="degC")
"Supply temperature set point for heating";
Modelica.Blocks.Interfaces.RealInput TCooSupSet(
final unit="K",
displayUnit="degC")
"Supply temperature set point for cooling";
equation
connect(disFloHea.TSupSet, THeaSupSet);
connect(disFloCoo.TSupSet, TCooSupSet);
end BuildingTimeSeries;
