Buildings.Fluid.HeatPumps.ModularReversible.Validation
Collection of validation models
Information
This package contains validation models for the classes in Buildings.Fluid.HeatPumps.ModularReversible.
Note that most validation models contain simple input data which may not be realistic, but for which the correct output can be obtained through an analytic solution. The examples plot various outputs, which have been verified against these solutions. These model outputs are stored as reference data and used for continuous validation whenever models in the library change.
Extends from Modelica.Icons.ExamplesPackage (Icon for packages containing runnable examples).
Package Content
| Name | Description |
|---|---|
 ConstantCarnotEffectiveness
|
|
| TableData2D
|
|
 TableData2DLoadDepSHC
|
|
 Comparative
|
Package for comparative model validation |
 BaseClasses
|
Partial validation models |
Buildings.Fluid.HeatPumps.ModularReversible.Validation.ConstantCarnotEffectiveness
Information
This validation case uses a constant Carnot effectiveness to model the efficiency of the heat pump.
The approach was calibrated as a comparison to table-based data in the conference paper for the heat pump model: https://doi.org/10.3384/ecp21181561
Extends from Modelica.Icons.Example (Icon for runnable examples), Buildings.Fluid.HeatPumps.ModularReversible.Validation.BaseClasses.PartialValidation (Validation base case for the reversible heat pump model.).
Parameters
| Type | Name | Default | Description |
|---|---|---|---|
| replaceable package MediumSin | Water | Medium of sink side | |
| replaceable package MediumSou | Water | Medium of source side | |
| Real | etaCarnot_nominal | 0.4318 | Calibrated constant Carnot effectiveness |
| Power | PEle_nominal | 1884.218212 | Calibrated nominal electrical power consumption [W] |
| MassFlowRate | mCon_flow_nominal | 0.407396 | Calibrated condenser nominal mass flow rate [kg/s] |
| Volume | VCon | 0.0015972 | Calibrated condenser volume [m3] |
| Frequency | refIneFreConst | 13.2e-3 | Calibrated cut off frequency for inertia of refrigerant cycle [Hz] |
Connectors
| Type | Name | Description |
|---|---|---|
| output RealOutput | TConOutMea | Measured condenser outlet [K] |
| output RealOutput | TEvaOutMea | Measured evaporator outlet [K] |
| output RealOutput | PEleMea | Measured electrical power consumption [W] |
| output RealOutput | PEleSim | Simulated electrical power consumption [W] |
| output RealOutput | TConOutSim | Simulated condenser outlet [K] |
| output RealOutput | TEvaOutSim | Simulated evaporator outlet [K] |
Modelica definition
model ConstantCarnotEffectiveness
extends Modelica.Icons.Example;
extends Buildings.Fluid.HeatPumps.ModularReversible.Validation.BaseClasses.PartialValidation
(
heaPum(
QHea_flow_nominal=etaCarnot_nominal*PEle_nominal*heaPum.TConHea_nominal/(heaPum.TConHea_nominal
- heaPum.TEvaHea_nominal),
mCon_flow_nominal=mCon_flow_nominal,
tauCon=VCon*heaPum.rhoCon/mCon_flow_nominal,
redeclare model RefrigerantCycleInertia =
Buildings.Fluid.HeatPumps.ModularReversible.RefrigerantCycle.Inertias.VariableOrder
(
refIneFreConst=refIneFreConst,
nthOrd=2,
initType=Modelica.Blocks.Types.Init.InitialState),
redeclare model RefrigerantCycleHeatPumpHeating =
Buildings.Fluid.HeatPumps.ModularReversible.RefrigerantCycle.ConstantCarnotEffectiveness
(TAppCon_nominal=0,
TAppEva_nominal=0,
etaCarnot_nominal=etaCarnot_nominal)));
parameter Real etaCarnot_nominal=0.4318 "Calibrated constant Carnot effectiveness";
parameter Modelica.Units.SI.Power PEle_nominal=1884.218212
"Calibrated nominal electrical power consumption";
parameter Modelica.Units.SI.MassFlowRate mCon_flow_nominal=0.407396
"Calibrated condenser nominal mass flow rate";
parameter Modelica.Units.SI.Volume VCon=0.0015972
"Calibrated condenser volume";
parameter Modelica.Units.SI.Frequency refIneFreConst=13.2e-3
"Calibrated cut off frequency for inertia of refrigerant cycle";
end ConstantCarnotEffectiveness;
Buildings.Fluid.HeatPumps.ModularReversible.Validation.TableData2D
Information
This validation case uses table-based data for the heat pump.
The approach was calibrated as a comparison to constant Carnot effectiveness approach in the conference paper for the heat pump model: https://doi.org/10.3384/ecp21181561
Extends from Modelica.Icons.Example (Icon for runnable examples), Buildings.Fluid.HeatPumps.ModularReversible.Validation.BaseClasses.PartialValidation (Validation base case for the reversible heat pump model.).
Parameters
| Type | Name | Default | Description |
|---|---|---|---|
| replaceable package MediumSin | Water | Medium of sink side | |
| replaceable package MediumSou | Water | Medium of source side | |
| MassFlowRate | mCon_flow_nominal | 0.404317 | Condenser nominal mass flow rate [kg/s] |
| Volume | VCon | 0.004473 | Condenser volume [m3] |
| Frequency | refIneFreConst | 0.011848 | Cut off frequency for inertia of refrigerant cycle [Hz] |
Connectors
| Type | Name | Description |
|---|---|---|
| output RealOutput | TConOutMea | Measured condenser outlet [K] |
| output RealOutput | TEvaOutMea | Measured evaporator outlet [K] |
| output RealOutput | PEleMea | Measured electrical power consumption [W] |
| output RealOutput | PEleSim | Simulated electrical power consumption [W] |
| output RealOutput | TConOutSim | Simulated condenser outlet [K] |
| output RealOutput | TEvaOutSim | Simulated evaporator outlet [K] |
Modelica definition
model TableData2D
extends Modelica.Icons.Example;
extends Buildings.Fluid.HeatPumps.ModularReversible.Validation.BaseClasses.PartialValidation
(
heaPum(
QHea_flow_nominal=heaPum.refCyc.refCycHeaPumHea.QHeaNoSca_flow_nominal,
mCon_flow_nominal=mCon_flow_nominal,
tauCon=VCon*heaPum.rhoCon/mCon_flow_nominal,
redeclare model RefrigerantCycleInertia =
Buildings.Fluid.HeatPumps.ModularReversible.RefrigerantCycle.Inertias.VariableOrder
(
refIneFreConst=refIneFreConst,
nthOrd=2,
initType=Modelica.Blocks.Types.Init.InitialState),
redeclare model RefrigerantCycleHeatPumpHeating =
Buildings.Fluid.HeatPumps.ModularReversible.RefrigerantCycle.TableData2D (
datTab=
Buildings.Fluid.HeatPumps.ModularReversible.Data.TableData2D.GenericHeatPump(
tabPEle=[0,273.15,283.15; 308.15,1300,1500; 328.15,1900,2300],
mCon_flow_nominal=6100/5/4184,
mEva_flow_nominal=4800/5/4184,
dpCon_nominal=0,
dpEva_nominal=0,
devIde="Vaillaint_VWL101",
use_TEvaOutForTab=false,
use_TConOutForTab=true,
tabQCon_flow=[0,273.15,283.15; 308.15,6100,8400; 328.15,5700,7600],
tabUppBou=[-40,70; 40,70]))));
parameter Modelica.Units.SI.MassFlowRate mCon_flow_nominal=0.404317
"Condenser nominal mass flow rate";
parameter Modelica.Units.SI.Volume VCon=0.004473
"Condenser volume";
parameter Modelica.Units.SI.Frequency refIneFreConst=0.011848
"Cut off frequency for inertia of refrigerant cycle";
end TableData2D;
Buildings.Fluid.HeatPumps.ModularReversible.Validation.TableData2DLoadDepSHC
Information
This model validates the hydronics and built-in control logic of Buildings.Fluid.HeatPumps.ModularReversible.TableData2DLoadDepSHC.
The model represents a three-module system where the HW and CHW isolation
valves are modeled using an equivalent actuator.
The actuator model represents the parallel network of the modules'
condenser or evaporator barrels in series with the HW or CHW isolation valves.
It is parameterized with the flow characteristics calculated
by the heat pump model, and controlled by the output variables provided
by this model.
The heat pump operating mode switches between simultaneous heating and cooling,
heating only, and cooling only.
The on/off command starts as true and is switched to
false at the end.
While the heat pump component is subjected to the design HW and CHW differential pressures and return temperatures, the supply temperature setpoints vary, creating a varying load. The validation then consists in verifying that the modules are effectively staged in various modes to adapt to the load. Additionally, it confirms that the isolation valve parameterization and controls result in HW and CHW flow rates that vary linearly with the number of enabled modules on each side.
Extends from Modelica.Icons.Example (Icon for runnable examples).
Parameters
| Type | Name | Default | Description |
|---|---|---|---|
| replaceable package Medium | Buildings.Media.Water | HW or CHW medium | |
| Generic | dat | dat(PLRHeaSup={1}, PLRCooSup... | Performance data |
| Nominal condition | |||
| Temperature | THwSup_nominal | 323.15 | HW supply temperature [K] |
| Temperature | THwRet_nominal | 315.15 | HW return temperature [K] |
| Temperature | TChwSup_nominal | 280.15 | CHW supply temperature [K] |
| Temperature | TChwRet_nominal | 285.15 | CHW return temperature [K] |
| MassFlowRate | mHw_flow_nominal | QHea_flow_nominal/(THwSup_no... | HW mass flow rate [kg/s] |
| MassFlowRate | mChw_flow_nominal | QCoo_flow_nominal/(TChwSup_n... | CHW mass flow rate [kg/s] |
| Nominal condition - Heating mode | |||
| Temperature | TAmbHea_nominal | 268.15 | OA temperature [K] |
| HeatFlowRate | QHea_flow_nominal | 58E3 | Heating heat flow rate - Heating mode [W] |
| HeatFlowRate | QHeaShc_flow_nominal | 85E3 | Heating heat flow rate - SHC mode [W] |
| Nominal condition - Cooling mode | |||
| Temperature | TAmbCoo_nominal | 308.15 | Ambient side fluid temperature — Entering or leaving depending on use_TAmbOutForTab [K] |
| HeatFlowRate | QCoo_flow_nominal | -73E3 | Cooling heat flow rate - Cooling mode [W] |
| HeatFlowRate | QCooShc_flow_nominal | -65E3 | Cooling heat flow rate - SHC mode [W] |
| Dynamics | |||
| Conservation equations | |||
| Dynamics | energyDynamics | Modelica.Fluid.Types.Dynamic... | Type of energy balance: dynamic (3 initialization options) or steady state |
Connectors
| Type | Name | Description |
|---|---|---|
| replaceable package Medium | HW or CHW medium | |
| Bus | weaBus | |
Modelica definition
model TableData2DLoadDepSHC
extends Modelica.Icons.Example;
replaceable package Medium=Buildings.Media.Water
constrainedby Modelica.Media.Interfaces.PartialMedium
"HW or CHW medium";
parameter Modelica.Fluid.Types.Dynamics energyDynamics=Modelica.Fluid.Types.Dynamics.FixedInitial
"Type of energy balance: dynamic (3 initialization options) or steady state";
parameter Modelica.Units.SI.Temperature THwSup_nominal=323.15
"HW supply temperature";
parameter Modelica.Units.SI.Temperature THwRet_nominal=315.15
"HW return temperature";
parameter Modelica.Units.SI.Temperature TChwSup_nominal=280.15
"CHW supply temperature";
parameter Modelica.Units.SI.Temperature TChwRet_nominal=285.15
"CHW return temperature";
parameter Modelica.Units.SI.Temperature TAmbHea_nominal=268.15
"OA temperature";
parameter Modelica.Units.SI.HeatFlowRate QHea_flow_nominal = 58E3
"Heating heat flow rate - Heating mode";
parameter Modelica.Units.SI.HeatFlowRate QHeaShc_flow_nominal = 85E3
"Heating heat flow rate - SHC mode";
parameter Modelica.Units.SI.Temperature TAmbCoo_nominal=308.15
"Ambient side fluid temperature — Entering or leaving depending on use_TAmbOutForTab";
parameter Modelica.Units.SI.HeatFlowRate QCoo_flow_nominal = -73E3
"Cooling heat flow rate - Cooling mode";
parameter Modelica.Units.SI.HeatFlowRate QCooShc_flow_nominal = -65E3
"Cooling heat flow rate - SHC mode";
parameter Modelica.Units.SI.MassFlowRate mHw_flow_nominal=
QHea_flow_nominal / (THwSup_nominal - THwRet_nominal) /
Buildings.Media.Water.cp_const
"HW mass flow rate";
parameter Modelica.Units.SI.MassFlowRate mChw_flow_nominal=
QCoo_flow_nominal / (TChwSup_nominal - TChwRet_nominal) /
Buildings.Media.Water.cp_const
"CHW mass flow rate";
Buildings.Controls.OBC.CDL.Reals.Sources.TimeTable TChiWatSet(
table=[0,0; 10,0; 80,0.2*(TChwEnt.k - TChwSup_nominal); 95,0.2*(TChwEnt.k
- TChwSup_nominal)],
offset={TChwSup_nominal},
timeScale=20,
y(each final unit="K", each displayUnit="degC"))
"CHW supply or return temperature setpoint";
Buildings.Controls.OBC.CDL.Reals.Sources.Sin THeaWatSet(
amplitude=THwEnt.k - THwSup_nominal,
freqHz=1/3600,
offset=THwSup_nominal,
startTime=1000,
y(final unit="K", displayUnit="degC"))
"HW supply or return temperature setpoint";
Buildings.Controls.OBC.CDL.Reals.Sources.Constant THwEnt(k=THwSup_nominal +
(THwRet_nominal - THwSup_nominal)*QHeaShc_flow_nominal/QHea_flow_nominal,
y(final unit="K", displayUnit="degC")) "Condenser entering HW temperature";
Buildings.Controls.OBC.CDL.Reals.Sources.Constant TChwEnt(k=TChwSup_nominal +
(TChwRet_nominal - TChwSup_nominal)* QCooShc_flow_nominal /QCoo_flow_nominal,
y(final unit="K", displayUnit="degC"))
"Evaporator entering CHW temperature";
Buildings.Controls.OBC.CDL.Reals.Sources.Constant TOut(k=15 + 273.15, y(
final unit="K", displayUnit="degC")) "OA temperature";
Buildings.Controls.OBC.CDL.Reals.Min min1;
Buildings.Controls.OBC.CDL.Reals.Sources.Constant THeaWatSupNom(k=
THwSup_nominal, y(final unit="K", displayUnit="degC"))
"Design HW supply temperature";
Buildings.Controls.OBC.CDL.Logical.Sources.TimeTable onCoo(
table=[0,0; 500,1; 2400,0; 3600,1; 5000,0],
period=5400)
"Cooling on/off command";
Buildings.Controls.OBC.CDL.Logical.Sources.TimeTable onHea(
table=[0,0; 500,1; 1200,0; 2400,1; 4800,0],
period=5400)
"Heating on/off command";
Buildings.Fluid.HeatPumps.ModularReversible.TableData2DLoadDepSHC hp(
redeclare final package MediumCon=Medium,
redeclare final package MediumEva=Medium,
final energyDynamics=energyDynamics,
nUni=3,
use_preDro=false,
dpHw_nominal=30000,
dpChw_nominal=40000,
final dat=dat,
mCon_flow_nominal=mHw_flow_nominal,
mEva_flow_nominal=mChw_flow_nominal,
final QHea_flow_nominal=QHea_flow_nominal,
QCoo_flow_nominal=QCoo_flow_nominal,
final QHeaShc_flow_nominal=QHeaShc_flow_nominal,
final QCooShc_flow_nominal=QCooShc_flow_nominal,
final TConHea_nominal=THwSup_nominal,
final TEvaHea_nominal=TAmbHea_nominal,
TConCoo_nominal=TChwSup_nominal,
TEvaCoo_nominal=TAmbCoo_nominal)
"Multipipe heat pump";
BoundaryConditions.WeatherData.Bus weaBus;
parameter Data.TableData2DLoadDepSHC.Generic dat(
PLRHeaSup={1},
PLRCooSup={1},
PLRShcSup={1},
fileNameHea=Modelica.Utilities.Files.loadResource("modelica://Buildings/Resources/Data/Fluid/HeatPumps/ModularReversible/RefrigerantCycle/BaseClasses/Validation/AWHP_Heating.txt"),
fileNameCoo=Modelica.Utilities.Files.loadResource("modelica://Buildings/Resources/Data/Fluid/HeatPumps/ModularReversible/RefrigerantCycle/BaseClasses/Validation/AWHP_Cooling.txt"),
fileNameShc=Modelica.Utilities.Files.loadResource("modelica://Buildings/Resources/Data/Fluid/HeatPumps/ModularReversible/RefrigerantCycle/BaseClasses/Validation/AWHP_SHC.txt"),
mCon_flow_nominal=1.7,
mEva_flow_nominal=3.5,
dpCon_nominal=30E3,
dpEva_nominal=40E3,
devIde="",
use_TEvaOutForTab=true,
use_TConOutForTab=true) "Performance data";
Sources.Boundary_pT hwIn(
redeclare final package Medium = Medium,
p=hwOut.p + hp.dpHw_nominal + hp.dpValIso_nominal,
use_T_in=true,
nPorts=1) "Boundary conditions of HW at HP inlet";
Sources.Boundary_pT hwOut(
redeclare final package Medium = Medium,
p=Buildings.Templates.Data.Defaults.pHeaWat_rel_nominal + 101325,
nPorts=1) "Boundary conditions of HW at HP outlet";
Sources.Boundary_pT chwOut(
redeclare final package Medium = Medium,
p=Buildings.Templates.Data.Defaults.pChiWat_rel_nominal + 101325,
nPorts=1) "Boundary conditions of CHW at HP outlet";
Sources.Boundary_pT chwIn(
redeclare final package Medium = Medium,
p=chwOut.p + hp.dpChw_nominal + hp.dpValIso_nominal,
use_T_in=true,
nPorts=1) "Boundary conditions of CHW at HP inlet";
Sensors.TemperatureTwoPort THwSup(
redeclare final package Medium = Medium,
final m_flow_nominal=hp.mCon_flow_nominal,
initType=Modelica.Blocks.Types.Init.InitialOutput,
T_start=THwSup_nominal) "HW supply temperature";
Sensors.TemperatureTwoPort THwRet(
redeclare final package Medium = Medium,
final m_flow_nominal=hp.mCon_flow_nominal,
initType=Modelica.Blocks.Types.Init.InitialOutput,
T_start=THwRet_nominal) "HW return temperature";
Sensors.TemperatureTwoPort TChwRet(
redeclare final package Medium = Medium,
final m_flow_nominal=hp.mEva_flow_nominal,
initType=Modelica.Blocks.Types.Init.InitialOutput,
T_start=TChwRet_nominal) "CHW return temperature";
Sensors.TemperatureTwoPort TChwSup(
redeclare final package Medium = Medium,
final m_flow_nominal=hp.mEva_flow_nominal,
initType=Modelica.Blocks.Types.Init.InitialOutput,
T_start=TChwSup_nominal) "CHW supply temperature";
Actuators.Valves.TwoWayTable valHwIso(
redeclare final package Medium = Medium,
final m_flow_nominal=hp.mCon_flow_nominal,
flowCharacteristics=hp.chaValHwIso,
dpValve_nominal=hp.dpValIso_nominal,
strokeTime=10,
init=Modelica.Blocks.Types.Init.InitialState,
dpFixed_nominal=hp.dpHw_nominal)
"Equivalent actuator for modules' condenser barrels and HW isolation valves";
Actuators.Valves.TwoWayTable valChwIso(
redeclare final package Medium = Medium,
final m_flow_nominal=hp.mEva_flow_nominal,
dpValve_nominal=hp.dpValIso_nominal,
init=Modelica.Blocks.Types.Init.InitialState,
dpFixed_nominal=hp.dpChw_nominal,
flowCharacteristics=hp.chaValChwIso)
"Equivalent actuator for modules' evaporator barrels and CHW isolation valves";
Buildings.Controls.OBC.CDL.Integers.MultiSum sumNumUni(nin=3)
"Total number of enabled modules";
Buildings.Controls.OBC.CDL.Utilities.Assert assMes(message=
"Number of enabled modules exceeds number of modules")
"Assert condition on number of enabled modules";
Buildings.Controls.OBC.CDL.Integers.LessEqualThreshold intLesEquThr(t=hp.nUni)
"True if number of enabled modules lower or equal to number of modules";
equation
connect(THeaWatSet.y, min1.u1);
connect(THeaWatSupNom.y, min1.u2);
connect(min1.y, hp.THwSet);
connect(TChiWatSet.y[1], hp.TChwSet);
connect(onHea.y[1], hp.onHea);
connect(TOut.y, weaBus.TDryBul);
connect(weaBus, hp.weaBus);
connect(THwEnt.y, hwIn.T_in);
connect(TChwEnt.y, chwIn.T_in);
connect(THwSup.port_b, hwOut.ports[1]);
connect(hwIn.ports[1], THwRet.port_a);
connect(THwRet.port_b, hp.port_a1);
connect(chwIn.ports[1], TChwRet.port_a);
connect(TChwRet.port_b, hp.port_a2);
connect(chwOut.ports[1], TChwSup.port_b);
connect(hp.port_b1, valHwIso.port_a);
connect(valHwIso.port_b, THwSup.port_a);
connect(TChwSup.port_a, valChwIso.port_b);
connect(hp.port_b2, valChwIso.port_a);
connect(hp.yValHwIso, valHwIso.y);
connect(hp.yValChwIso, valChwIso.y);
connect(hp.nUniHea, sumNumUni.u[1]);
connect(hp.nUniCoo, sumNumUni.u[2]);
connect(hp.nUniShc, sumNumUni.u[3]);
connect(sumNumUni.y, intLesEquThr.u);
connect(intLesEquThr.y, assMes.u);
connect(onCoo.y[1], hp.onCoo);
end TableData2DLoadDepSHC;
