Buildings.Controls.OBC.ASHRAE.G36.FanCoilUnits.Validation
Package of validation models for fan coil unit controls
Information
This package contains the validation model for the fan coil unit controller.
Package Content
| Name | Description |
|---|---|
 Controller
|
Validation of the top-level controller |
Buildings.Controls.OBC.ASHRAE.G36.FanCoilUnits.Validation.Controller
Validation of the top-level controller
Information
This example validates Buildings.Controls.OBC.ASHRAE.G36.FanCoilUnits.Controller.
conFCU represents an instance of the controller with heating mode
operation, with the open-loop signals for measured zone temperature and measured
supply air temperature increasing with time.
conFCU1 represents an instance of the controller with cooling mode
operation, with the open-loop signals for measured zone temperature and measured
supply air temperature decreasing with time.
conFCU2 and conFCU3 represent instances of the controller
with cooling mode operation, with different parameter settings for the window and occupancy sensors.
Modelica definition
model Controller
"Validation of the top-level controller"
Buildings.Controls.OBC.ASHRAE.G36.FanCoilUnits.Controller conFCU(
cooCoi=Buildings.Controls.OBC.ASHRAE.G36.Types.CoolingCoil.WaterBased,
heaCoi=Buildings.Controls.OBC.ASHRAE.G36.Types.HeatingCoil.WaterBased,
have_winSen=false,
kHea=1,
cooConTyp=Buildings.Controls.OBC.CDL.Types.SimpleController.P,
heaConTyp=Buildings.Controls.OBC.CDL.Types.SimpleController.P,
have_occSen=true,
TSupSet_max=297.15,
TSupSet_min=285.15,
heaSpe_max=0.6,
heaSpe_min=0.2,
cooSpe_min=0.2,
have_locAdj=false)
"Validate the heating case";
Buildings.Controls.OBC.ASHRAE.G36.FanCoilUnits.Controller conFCU1(
cooCoi=Buildings.Controls.OBC.ASHRAE.G36.Types.CoolingCoil.WaterBased,
heaCoi=Buildings.Controls.OBC.ASHRAE.G36.Types.HeatingCoil.WaterBased,
have_winSen=true,
kCoo=1,
kHea=1,
cooConTyp=Buildings.Controls.OBC.CDL.Types.SimpleController.P,
heaConTyp=Buildings.Controls.OBC.CDL.Types.SimpleController.P,
have_occSen=false,
TSupSet_max=297.15,
TSupSet_min=285.15,
heaSpe_max=0.6,
heaSpe_min=0.2,
cooSpe_min=0.2,
have_locAdj=false)
"Validate the cooling case for a system with a window sensor but no occupancy sensor";
Buildings.Controls.OBC.ASHRAE.G36.FanCoilUnits.Controller conFCU2(
cooCoi=Buildings.Controls.OBC.ASHRAE.G36.Types.CoolingCoil.WaterBased,
heaCoi=Buildings.Controls.OBC.ASHRAE.G36.Types.HeatingCoil.WaterBased,
have_winSen=false,
kCoo=1,
kHea=1,
cooConTyp=Buildings.Controls.OBC.CDL.Types.SimpleController.P,
heaConTyp=Buildings.Controls.OBC.CDL.Types.SimpleController.P,
have_occSen=true,
TSupSet_max=297.15,
TSupSet_min=285.15,
heaSpe_max=0.6,
heaSpe_min=0.2,
cooSpe_min=0.2,
have_locAdj=false)
"Validate the cooling case for a system with an occupancy sensor but no window sensor";
Buildings.Controls.OBC.ASHRAE.G36.FanCoilUnits.Controller conFCU3(
cooCoi=Buildings.Controls.OBC.ASHRAE.G36.Types.CoolingCoil.WaterBased,
heaCoi=Buildings.Controls.OBC.ASHRAE.G36.Types.HeatingCoil.WaterBased,
have_winSen=true,
kCoo=1,
kHea=1,
cooConTyp=Buildings.Controls.OBC.CDL.Types.SimpleController.P,
heaConTyp=Buildings.Controls.OBC.CDL.Types.SimpleController.P,
have_occSen=true,
TSupSet_max=297.15,
TSupSet_min=285.15,
heaSpe_max=0.6,
heaSpe_min=0.2,
cooSpe_min=0.2,
have_locAdj=false)
"Validate the cooling case for a system with both a window sensor and an occupancy sensor";
Buildings.Controls.OBC.CDL.Reals.Sources.Constant TOccHeaSet(
k=293.15)
"Occupied heating setpoint temperature";
Buildings.Controls.OBC.CDL.Reals.Sources.Constant TOccCooSet(
k=297.15)
"Occupied cooling setpoint temperature";
Buildings.Controls.OBC.CDL.Reals.Sources.Constant TUnoHeaSet(
k=285.15)
"Unoccupied heating setpoint temperature";
Buildings.Controls.OBC.CDL.Reals.Sources.Constant TUnoCooSet(
k=303.15)
"Unoccupied cooling setpoint temperature";
Buildings.Controls.OBC.CDL.Reals.Sources.Ramp TZon(
duration=86400,
height=6,
offset=273.15 + 16,
y(unit="K"))
"Measured zone temperature";
Buildings.Controls.SetPoints.OccupancySchedule occSch(
occupancy=3600*{4,20})
"Occupancy schedule";
Buildings.Controls.OBC.CDL.Integers.Sources.Constant nOcc(
k=2)
"Number of occupants";
Buildings.Controls.OBC.CDL.Logical.Sources.Constant win(
k=true)
"True window status";
Buildings.Controls.OBC.CDL.Reals.Sources.Ramp TZon1(
duration=86400,
height=-3,
offset=273.15 + 26,
y(unit="K"))
"Measured zone temperature";
Buildings.Controls.OBC.CDL.Reals.Sources.Ramp TSup(
height=2,
duration=86400,
offset=273.15 + 22.5,
y(unit="K"))
"Terminal unit discharge air temperature";
Buildings.Controls.OBC.CDL.Reals.Sources.Ramp TSup1(
height=-3,
duration=86400,
offset=273.15 + 24,
y(unit="K"))
"Terminal unit discharge air temperature";
Buildings.Controls.OBC.CDL.Integers.Sources.Constant demLim(
k=0)
"Cooling and heating demand imit level";
Buildings.Controls.OBC.CDL.Reals.Sources.Constant cooWarTim(
k=0)
"Cooldown and warm-up time";
Buildings.Controls.OBC.CDL.Logical.Sources.Constant win1(
k=false)
"Negative window status";
equation
connect(TZon.y,conFCU. TZon);
connect(occSch.occupied,conFCU. u1Occ);
connect(occSch.tNexOcc,conFCU. tNexOcc);
connect(TSup.y,conFCU. TSup);
connect(win.y,conFCU1. u1Win);
connect(occSch.tNexOcc,conFCU1. tNexOcc);
connect(occSch.occupied,conFCU1. u1Occ);
connect(TZon1.y,conFCU1. TZon);
connect(TSup1.y,conFCU1. TSup);
connect(TSup1.y,conFCU2. TSup);
connect(occSch.occupied,conFCU2. u1Occ);
connect(occSch.tNexOcc,conFCU2. tNexOcc);
connect(TZon1.y,conFCU2. TZon);
connect(occSch.occupied,conFCU3. u1Occ);
connect(TSup1.y,conFCU3. TSup);
connect(TZon1.y,conFCU3. TZon);
connect(occSch.tNexOcc,conFCU3. tNexOcc);
connect(cooWarTim.y,conFCU. warUpTim);
connect(cooWarTim.y,conFCU. cooDowTim);
connect(cooWarTim.y,conFCU1. warUpTim);
connect(cooWarTim.y,conFCU1. cooDowTim);
connect(cooWarTim.y,conFCU2. warUpTim);
connect(cooWarTim.y,conFCU2. cooDowTim);
connect(cooWarTim.y,conFCU3. warUpTim);
connect(cooWarTim.y,conFCU3. cooDowTim);
connect(demLim.y,conFCU3. uHeaDemLimLev);
connect(demLim.y,conFCU3. uCooDemLimLev);
connect(demLim.y,conFCU2. uHeaDemLimLev);
connect(demLim.y,conFCU2. uCooDemLimLev);
connect(demLim.y,conFCU1. uHeaDemLimLev);
connect(demLim.y,conFCU1. uCooDemLimLev);
connect(demLim.y,conFCU. uCooDemLimLev);
connect(demLim.y,conFCU. uHeaDemLimLev);
connect(nOcc.y, conFCU.nOcc);
connect(nOcc.y, conFCU2.nOcc);
connect(TOccHeaSet.y, conFCU.TOccHeaSet);
connect(TOccCooSet.y, conFCU.TOccCooSet);
connect(TUnoHeaSet.y, conFCU.TUnoHeaSet);
connect(TUnoCooSet.y, conFCU.TUnoCooSet);
connect(TOccHeaSet.y, conFCU1.TOccHeaSet);
connect(TOccCooSet.y, conFCU1.TOccCooSet);
connect(TUnoHeaSet.y, conFCU1.TUnoHeaSet);
connect(TUnoCooSet.y, conFCU1.TUnoCooSet);
connect(TOccHeaSet.y, conFCU2.TOccHeaSet);
connect(TOccCooSet.y, conFCU2.TOccCooSet);
connect(TUnoHeaSet.y, conFCU2.TUnoHeaSet);
connect(TUnoCooSet.y, conFCU2.TUnoCooSet);
connect(TOccHeaSet.y, conFCU3.TOccHeaSet);
connect(TOccCooSet.y, conFCU3.TOccCooSet);
connect(TUnoHeaSet.y, conFCU3.TUnoHeaSet);
connect(TUnoCooSet.y, conFCU3.TUnoCooSet);
connect(conFCU1.y1Fan, conFCU1.u1Fan);
connect(conFCU2.y1Fan, conFCU2.u1Fan);
connect(conFCU3.y1Fan, conFCU3.u1Fan);
connect(conFCU.y1Fan, conFCU.u1Fan);
connect(nOcc.y, conFCU3.nOcc);
connect(win1.y, conFCU3.u1Win);
end Controller;
